Oscilloscopes

51 products


  •  -20% FNIRSI DSO-TC3 (3-in-1) Oscilloscope, Component Tester & Signal Generator

    FNIRSI FNIRSI DSO-TC3 (3-in-1) Oscilloscope, Component Tester & Signal Generator

    DSO-TC3 combines a digital oscilloscope, electronic component tester, signal generator, continuity test, voltage test, temperature and humidity measurement, infrared decoding and other functions are skillfully integrated. It is equipped with a 2.4' color TFT display and a built-in rechargeable lithium battery for mobile use. Specifications (Oscilloscope) The oscilloscope has a real-time sampling rate of 10 MSa/s and a bandwidth of 500 kHz. With complete trigger function (single, normal, automatic), no matter if you’re using periodic analog signals or non-periodic digital signals. Maximum measured voltage signal is 400 V. Equipped with efficient AUTO, the measured waveform can be displayed without cumbersome adjustments. Real-time sample rate 10 MSa/s Bandwidth 500 khz Input resistance 1 MΩ Coupling method AC/DC Test voltage range 400 V Vertical Sensitivity (x1) 10 mV-10 V Horizontal time base range 1us-10s Trigger mode Auto/Normal/Single Trigger type Rising edge/Falling edge Waveform Freeze Yes Automatic measurement Yes Specifications (Component Tester) The instrument can automatically identify and measure various transistors, including NPN and PNP triodes, N-channel and P-channel mosfet, junction mosfet, diodes, dual diodes, thyristors, and resistors, inductors, capacitors and other passive components. Automatic detection of pin definition. Automatically analyze NEC protocol infrared code. Other functional modes: Including circuit continuity test, 0-40 V input voltage measurement, PWM output, 0-32 V regulated diode measurement, DS18B20 temperature sensor measurement, DHT11 temperature and humidity sensor measurement, etc. Specifications (Signal Generator) The signal generator has a total of 6 waveforms to choose from, with adjustable frequency and amplitude. Sine wave 1-100 KHz/0-3.3 V/50% Square wave 1-100 KHz/3.3 V/50% Pulse wave 1-100 KHz/3.3 V/0-100% Triangle wave 1-100 KHz/0-3.3 V/50% Ramp 1-100 KHz/0-3.3 V/0-100% DC 0-3.3 V Included 1x DSO-TC3 1x P6100 Oscilloscope Probe (100 MHz) 3x Test Hooks 1x Adapter 1x USB-C Cable 1x Original Manual by FNIRSI (English, Chinese, Russian, Portuguese) 1x Elektor Manual (English, French, German, Italian, Dutch) Downloads Original Manual Firmware v0.3

    € 74,95€ 59,95

    Members identical

  •  -20% OWON SDS1102 2-kanaals Oscilloscoop (100 MHz)

    OWON OWON SDS1102 2-ch Oscilloscope (100 MHz)

    OWON SDS1102 is an affordable desktop digital oscilloscope with top features: 2-channel device with 100 MHz bandwidth, 1 GSa/s sample rate, 7' LCD display and 10 K pts wavelength. OWON SDS1102 has a simplified synchronization system which supports two trigger types: level and edge. Designed to solve problems that do not require large amounts of memory and difficult trigger types. Features Bandwidth: 100 MHz 2 channels Sample rate: 100 MS/s Ultra-thin body 7-inch high resolution LCD SCPI and LabVIEW supported Specifications Bandwidth 100 MHz Horizontal Scale (s/div) 5 ns/div – 1000 s/div Channel 2 Vertical Sensitivity 5 mV/div – 5 V/div (at input) DC Gain Accuracy 3% Vertical Resolution (A/D) 8 bits (2 channels simultaneously) Input Input Impedance 1 MΩ, 10 pF Input Coupling AC, DC, GND Max Input Voltage ±400 V, CATI, CATII Passive probes х1; х10 Probe Attenuation Factor х1; х10; х100; х1000 Trigger System Trigger Mode Auto, Normal, Single Trigger Type Edge, Video Edge Trigger Source CH1, CH2 Video Trigger Sampling Type real-time Sample Rate 1 GSa/s Equivalent Sample Rate No Wavelength 10K pts Interpolation sin(x)/x Measurement and Mathematical Treatment System Automatic Measurement Vpp, Vavg, RMS, Frequency, Period, Vmax, Vmin, Vtop, Vbase, Width, Overshoot, Pre-shootRise time, Fall time, +Width, -Width, +Duty, -Duty, Delay A→B, Delay A→B, area, cycle area Math Functions Addition, Subtraction, Multiplication, Division, FFT General Characteristics Display type 7' color LCD Display Resolution 800 x 480 Power 100-240 V, 45-440 Hz, <15 W Dimensions 301 x 70 x 152 mm Weight 1.1 kg Included 1x OWON SDS1102 Oscilloscope 2x Oscilloscope probe 1x Probe Adjust 1x Mains power cord 1x USB Cable 1x CD-Rom 1x Quickstart Guide Downloads User manual Datasheet

    € 249,00€ 199,00

    Members identical

  •  -37% LabNation SmartScope USB-oscilloscoop

    LabNation LabNation SmartScope USB Oscilloscope

    3 reviews

    Smartscope is the only scope in the world that runs on all major platforms: Windows, macOS, Linux, Android and iOS (with WiFi bridge). Connect the SmartScope to pretty much any device! Even more, you can get mobile with it: take the SmartScope on the road, thanks to the single-cable connectivity. Everything is going to be intuitive: pointing, pinching and swiping finally replaces the clunky interfaces of old scopes. With the SmartScope you develop your digital interfaces using the 100 MS/s logic analyzer. With this tool you can design any signal you want using Excel, then upload it to the built-in Arbitrary Waveform Generator (AWG). At the end capture the voltage at any point of your design at 100 million times each second. The Software for the support of Windows / macOS) / Linux / Android and Export formats (Excel .csv / Matlab .mat) are given. Features Channel sampled at 100 MHz/s each AC/DC coupling on analog inputs 100% silent 64 Mbit RAM: x10000 zoom Arbitrary Waveform Generator 8 digital inputs at 100 MS/s each 4 digital outputs at 100 MS/s each Externally power your scope in case your mobile can't supply the juice. Specifications Oscilloscope Bandwidth 30 MHz (-3 dB point) Sample rate 2x 100 MS/s Channels 2 Max pre-trigger position 16x full scale Max post-trigger position Full scale Max full voltage scale 10 V/div (±35 V input range) Min full voltage scale 20 mV/div Analog input range -35 V, +35 V Max input peak-to-peak 40 V Signal coupling AC / DC Precision 8 bit Input impedance 1 MΩ // 10 pF Waverforms 200 waveforms/s Data delay to host < 10 ms Sample depth Up to 4 million samples per channel External trigger Yes Logic Analyzer Input channels 8 Input impedance 100 kOhm // 2 pF to GND Sample rate 100 MS/s Logic level 1.8 V to 5.0 V Diode protection Bidirectional Input data buffer 4 million samples Waverforms 200 waveforms/s Data delay to host < 10 ms Protocol decoders I²C, SPI, UART, I²S integrated User extensible Wave Generator (Analog Output) Output channels 1 Data rate Up to 50 MS/s Output level 0-3.3 V (Opamp driven) Output buffer Up to 2048 samples Max slew rate 30 ns/V Step 13 mV Wave Generator (Digital Output) Channels 4 Data rate Up to 100 MS/s Output level 3.3 V or 5 V (selectable) Output buffer Up to 2048 samples Diode protected Yes Programmable Logic USB controller MicroChip PIC18F14K50 USB interface PicKit3 or USB flashable FPGA Xilinx Spartan 6 FPGA interface JTAG and USB flashable Size & Weight Dimensions (L x W x D) 4.33 x 2.52 x 0.95' (110 x 64 x 24.2 mm) Weight 158 g Case Aluminium Connectivity Device/Host mini USB included Record waveforms Store Matlab (.mat) or Excel (.csv) files through Dropbox Analog BNC 2 probes included Digital 8x 0.1' pitch, probes (included) Sync USB micro B-B Power USB micro B (optional) Included 1x SmartScope USB Oscilloscope 2x Analog probes 1x Digital probe cable 1x Mini-B USB cable Downloads User manual Software GitHub Wiki

    € 239,00€ 149,95

    Members identical

  •  -21% FNIRSI 2C23T (3-in-1) 2-ch Oscilloscope (10 MHz) + Multimeter + Signal Generator

    FNIRI FNIRSI 2C23T (3-in-1) 2-ch Oscilloscope (10 MHz) + Multimeter + Signal Generator

    The FNIRSI 2C23T is a fully functional, highly practical 3-in-1 dual channel digital oscilloscope with a high resolution 2.8-inch LCD display (320 x 240 pixels) designed for the maintenance and development industry. This device is equipped with 3 main functions: oscilloscope, multimeter and signal generator. The oscilloscope has an FPGA+MCU+ADC hardware architecture with a sampling rate of 50 MS/s, an analog bandwidth of 10 MHz and a built-in high-voltage protection module that supports the measurement of peak voltages of ±400 V maximum. The multimeter has a 4-digit 10000-point RMS value and supports AC/DC voltage and current measurements, as well as capacitance, resistance, diode, on/off and other measurement functions. Equipped with a built-in DDS function signal generator, it can output 7 kinds of function signals, with a maximum output of 2 MHz for all signals and a step of 1 Hz; the output frequency, amplitude and duty cycle are adjustable. The built-in 3000 mAh rechargeable lithium battery achieves a standby time of up to 6 hours. Features 2-ch oscilloscope 10 MHz bandwidth 50 MS/s real-time sampling rate 7 signal waveforms 10000 counts 2.8' HD color display (320 x 240 pixels) Dimensions: 167 x 89 x 35 mm Weight: 300 g Specifications Oscilloscope Dual channel, 2x 10 MHz bandwidth, 50 MS/s real-time sampling rate Maximum measured voltage: ±400 V FPGA+ADC+MCU high-performance hardware architecture, capturing waveform details without loss Equipped with complete triggering functions (auto, single, normal) Equipped with efficient automatic adjustment, the measured waveform can be displayed without complicated adjustment Save waveform screenshots, supports exporting images to a computer, facilitate secondary waveform analysis Multimeter 4-bit integer 9999 counting True RMS measurement Identification of voltage, current, capacitance, resistance, diode, on/off, and zero live wire Maximum input voltage: AC 750 V, DC 1000 V Automatic range, intelligent anti burning Data retention, color screen digital display Signal Generator 7 signal waveforms: sine wave, square wave, triangular wave, full wave, half wave, noise wave, DC Output frequency: 1 Hz-2 MHz Output amplituade: 0.1-3.3 V Output duty cycle: 0-100% Included 1x FNIRSI 2C23T (3-in-1) 2-ch Oscilloscope 1x P6100 oscilloscope probes (10X) 1x Multimeter probe 1x Crocodile clip probe 1x USB-C charging cable 1x Original Manual by FNIRSI (English, German, Spanish, Portuguese, Russian, Chinese) 1x Elektor Manual (English, French, German, Dutch) Downloads Manual Firmware V2.0.2

    € 94,95€ 74,95

    Members identical

  •  -15% JOY-iT 3-in-1 Handheld Oscilloscoop, Signaalgenerator en Multimeter (DMSO2D72)

    JOY-iT JOY-iT 3-in-1 Handheld Oscilloscope, Signal Generator and Multimeter (DMSO2D72)

    The JOY-iT DMSO2D72 is your ideal companion for the workshop and outdoor use. It combines a 2-channel oscilloscope, a signal generator for any wave type as well as a multimeter with 6 different measurement types in one device and serves all functions you expect from individual devices. JOY-iT has placed particular emphasis on simple, clear and practical handling in order to make work as pleasant as possible for the user. For this the DMSOD72 is equipped with a 'one-button' auto measuring function and a 'one-button' page out. In addition, 2 signals can be compared directly on the 2.8' 65K colour LCD display. The power supply is provided by two 18650 lithium batteries, which are included in the scope of supply and allow a continuous operation of one day as well as a standby time of up to 8 weeks. Furthermore, operation via the USB-C interface is also possible, during which the batteries are charged simultaneously. In order to protect the device perfectly in 'outdoor use', the DMSO2D72 was equipped with a silicone sheath, which offers protection against shocks, dirt and heat. The extensive and very user-friendly software is available in English, German and French and can be switched easily on the device. You will also be impressed by the PC software, which provides you with a multitude of functions with very high ease of use. General Specifications Display type 2.8' 64K color TFT-LCD Display resolution 320 x 240 Display settings Adjustable background brightness, backlight duration, auto power off time Protective case Silicon cover, good impact resistance, outstanding heat resistance, easy to disassemble Special features Mobile use through battery operation, 3-in-1 device (oscilloscope, signal generator, multimeter), 3 languages (German, English, French) Assembly / Stand function 45° suspension bracket Interface USB Type C for power/data Rechargeable battery 2x 16850 Lithium Charging current 5 V / 2 A Battery life In use: A full dayIn standby: Up to 8 weeks PC software Windows 7 and higher Operating temperature 0-50°C Dimensions 199 x 98 x 40 mm Weight 624 g Oscilloscope Channels 2 + DMM + AWG Bandwidth 70 MHz Sampling Rate 250 MSa/s Single channel125 MSa/s Dual channel Vertical resolution 10 mV - 10 V Automatic measurement of Frequency and amplitude Manual cursor measurement Voltage and time Output impedance (DC) 25 pF ±3 pF; 1 MΩ ±2% Maximum input voltage 150 V RMS Signal Generator Sampling rate 250 MSa/s Vertical resolution 12 bits Waveforms Sine, square, triangle, trapezoid, and many more Sine 1 Hz - 25 MHz Square 1 Hz - 10 MHz Triangle 1 Hz - 1 MHz Trapezoid 1 Hz - 5 MHz Frequency resolution 1 Hz Output impedance 50 Ω Digital Multimeter 6 Multimeter measuring modes Voltage, current, resistance, capacity, diode, on-off Max. resolution 4000 Counts Ranges Voltage 0 µV - 600 V DC0 mV - 600 V AC, 40-400 Hz Current 0 µA - 10 A Resistance 0 mΩ - 40 MΩ Capacity 0 pF - 100 µF Diode 0-2 V On-off <50 Ω Included JOY-iT 3-in-1 Handheld DMSO2D72 2 rechargeable batteries (18650, 2600 mAh) Passive 80 MHz Probe + accessories 2x BNC to crocodile clip coaxial cable 2x DMM test lead USB to USB-C cable USB power supply (5 V, 2 A) Downloads JT-DMSO2D72 Datasheet JT-DMSO2D72 PC Software 1.1.10 JT-DMSO2D72 Manual Flash Manual 28-07-2021 Flash Software Latest firmware version (08-06-2021)

    € 259,00€ 219,00

    Members identical

  • FNIRSI DPOX180H (2-in-1) 2-ch Digital Phosphor Oscilloscope (180 MHz) & Signal Generator

    FNIRSI FNIRSI DPOX180H (2-in-1) 2-ch Digital Phosphor Oscilloscope (180 MHz) & Signal Generator

    1 review

    The FNIRSI DPOX180H is a cost-effective handheld dual-channel digital phosphor oscilloscope and signal generator. The oscilloscope has a real-time sampling rate of 500 MS/s and an analog bandwidth of 180 MHz. The measurement results are displayed on the high-contrast 2.8-inch IPS full-view LCD screen with digital fluorescence technology. Features 2-ch handheld oscilloscope & DDS signal generator 180 MHz bandwidth 500 MS/s sampling rate 20 MHz signal generator Innovative digital trigger system Cursor measurement function 5 mV sensitivity 50000 wfm/s waveform refresh rate 2.8' IPS full-vision high-definition display Built-in 4.2 V/3000 mAh lithium battery Automatic shutdown setting High-voltage anti-burning protection Specifications Nummer of channels 2 Analog bandwidth 180 MHz Maximum sampling rate 500 MS/s Input coupling DC/AC Rise time 2.5s Storage depth 120 Kpts Input impedance 1 MQ-18 PF Vertical sensitivity 5 mV-10 V (1X) Time base range 5 nS~50 S DC accuracy ±2% Time accuracy +0.01% Trigger detection Digital trigger Trigger mode Auto/Single/Normal Trigger edge Rising/Falling Measurement range 40 mV~80 V (1X) Screenshot storage 90 Capture signal 500 Screen size 2.8 inch Screen resolution 320 x 240 Display technology IPS full view Expansion interface USB transmission interface Auto power off 5 minutes - 2 hours Firmware upgrade Supported iso image upgrade Charging requirements 5 V/2 A Battery capacity 3000 mAh Standby time 3.5 hours at full charge Signal Generator 14 standard function signals Waveform storage 250 groups Parameter measurement 12 kinds Dimensions 135 x 90 x 40 mm Digital Phosphor Oscilloscope FNIRSI DPOX180H Oscilloscope uses the latest digital phosphor technology to overcome the traditional oscilloscope due to noise caused by the waveform burr feeling. Color temperature display function can more clearly see the distribution of the signal, probability characteristics and the rise and fall time of the step signal fast and slow. X-Y mode with digital phosphor technology for comparison of amplitude, frequency and phase of two groups of signals. DDS Function Signal Generator Built-in 20 MHz DDS function signal generator, with 14 kinds of standard function signals, output amplitude fixed at 1 VPP, sine wave frequency of 20 MHz, other waveform frequency of 10 MHz, adjustable frequency step of 1 Hz. Contains the original chopping technology, intercept part of the oscilloscope measurement of complex signals as the output signal of the signal generator, than the traditional signal generator hand-drawn signal more objective and realistic. Included 1x FNIRSI DPOX180H phosphor oscilloscope 2x Probes (200 MHz) 1x USB power supply 1x USB cable 1x Manual Downloads Manual Firmware V40

    € 159,95

    Members € 143,96

  • FNIRSI 1014D (2-in-1) 2-ch Oscilloscope (100 MHz) & Signal Generator

    FNIRSI FNIRSI 1014D (2-in-1) 2-ch Oscilloscope (100 MHz) & Signal Generator

    The FNIRSI 1014D is a 2-in-1 oscilloscope and signal generator with comprehensive functions and high practicality. It is a cost-effective 2-channel desktop oscilloscope for the maintenance industry and R&D industry. The oscilloscope has a real-time sampling rate of 1 GSa/s and an analog bandwidth of 100 MHz. The built-in DDS signal generator supports 12 types of function signals. Specifications Channels 2 Display size 7 inch LCD LCD resolution 800 x 480 Bandwidth 100 MHz Sampling rate 1 GSa/s Rise time <3nS Storage depth 240 Kbit Input resistance 1 MΩ Sensitivity 50 mV ~ 500 V Time base 50s ~ 10nS Trigger mode Single/Normal/Auto Trigger edge Rising/Falling Coupling AC/DC Highest test voltage 1X : 40V, 10X : 400V Cursor Position XY, Trigger Y Waveform storage 1000 pictures + 1000 waveforms Roll mode Yes One-button AUTO Yes Waveform manager Yes Capture output Yes Voltage accuracy ±5% Frequency precision ±0.01% high precision Parameter 12 kinds in total Generator 14 kinds in total Extension USB export Power supply 5 V/2 A, 3 A, 4 A Dimensions 310 x 145 x 70 mm Included 1x FNIRSI 1014D Oscilloscope 2x Oscilloscope probes (100 MHz) 1x USB charger 1x Manual Downloads User Guide

    € 169,95

    Members € 152,96

  • Last stock! LabNation Logic Analyzer Cable for SmartScope

    LabNation LabNation Logic Analyzer Cable for SmartScope

    1 in stock

    LabNation’s multifunctional SmartScope is not only a full-featured oscilloscope, but also a Logic Analyzer for digital-signal capturing. Optimal results though are only achieved with the use of shielded cables. Exactly for this purpose LabNation has developed a high-quality shielded cable, which prevents interference.

    1 in stock

    € 34,95

    Members € 31,46

  • OWON HDS272S 2-kanaals oscilloscoop (70 Mhz) + Multimeter + Signaalgenerator

    OWON OWON HDS272S 2-ch Oscilloscope (70 MHz) + Multimeter + Signal Generator

    The OWON HDS272S is the perfect solution all-in-one solution! Oscilloscope, multimeter and waveform generator in the same battery-powered device, to work on the go. Features Oscilloscope + multimeter + waveform generator, multifunction in one 3.5-inch high-resolution, high-contrast colour LCD display, suitable for outdoor use 18650 lithium battery, comprehensive power consumption ≤3 W, can work continuously for about 6 hours USB Type-C interface, support power bank, support PC software connection Self-calibration function SCPI supported, facilitate secondary development Specifications Oscilloscope Bandwidth 70 MHz Channels 2-ch Oscilloscope + 1-ch Generator Sample Rate 250 MSa/s Acquisition Model Normal, Peak detect Record Length 8K Display 3.5-inch LCD Waveform Refresh Rate 10,000 wfrms/s Input Coupling DC, AC, and Ground Input Impedance 1 MΩ ±2%, in parallel with 16pF±10pF Probe Attenuation Factors 1X,10X,100X,1000X,10000X Max. input Voltage 400 V (DC+AC, PK-PK, 1MΩ input impedance) (10:1 probe attenuation) Bandwidth Limit (typical) 20 MHz Horizontal Scale 5 ns/div - 1000 s/div, step by 1 - 2 - 5 Vertical Sensitivity 10 mV/div - 10 V/div Vertical Resolution 8 bits Trigger Type Edge Trigger Modes Auto, Normal, single Automatic Measurement Period, Frequency, Mean, PK-PK, Max, Min Cursor Measurement ΔV, ΔT, ΔT& ΔV between cursors Communication Interface USB Type-C Multimeter Max. Resolution 20,000 counts Testing Mode Voltage, Current, Resistance, Capacitance, Diode, and Continuity test Input Impedance 10 MΩ Max Input Voltage AC: 750 V | DC: 1000 V Max Input Current DC: 10 A | AC: 10 A Diode 0-2 V Waveform Generator Frequency Output Sine 0.1 Hz - 25 MHz Square 0.1 Hz - 5 MHz Ramp 0.1 Hz - 1 MHz Pulse 0.1 Hz - 5 MHz Arbitrary 0.1 Hz - 5 MHz Sampling Rate 125 MSa/s Channel 1-ch Amplitude Range 20 mVpp - 5 Vpp Waveform Length 8K Vertical Resolution 14 bits Output Impedance 50Ω Downloads User Manual for HDS200 Series SCPI Protocol for HDS200 Series Quick Guide for HDS200 Series PC Software for OWON HDS200 Series

    € 229,00

    Members € 206,10

  • JYE Tech DSO138mini Oscilloscope DIY Kit incl. BNC Probe & Enclosure

    JYE Tech JYE Tech DSO138mini Oscilloscope DIY Kit incl. BNC Probe & Enclosure

    Features USB or battery powered External trigger input Built-in 1KHz/3.3V test signal Waveform frozen (HOLD) function available Save/recall waveform Serial waveform data output Specifications Number of Channel 1 Analog Bandwidth 0 - 200 kHz Sensitivity 10 mV/Div - 5 V/Div Sensitivity error < 5% Resolution 12-bit Input Impedance 1 MΩ Maximum Input Voltage 50 Vpk Coupling DC, AC, GND Max Real-time Sampling Rate 1 Msps Timebase 10 us/Div - 500 s/Div Record Length 1024 Trigger Modes Auto, Normal, Single Trigger Types Rising / falling edge Trigger Position 1/2 of buffer size fixed Display 2.4-inch color TFT LCD with 320 x 240 resolution Power Supply 3.5 V - 6 V DC Supply Current 120 mA @ 5 V Dimension 85 x 75 x 15 mm Weight 50 g Note Power supply is not included. The user needs to prepare a USB cable with micro-USB style plug to run the oscilloscope. Any USB port with higher than 150 mA current capacity can be used as a power source for the oscilloscope. Included 1x DSO138mini kit with all SMD parts pre-soldered 1x User Manual Downloads Manual Enclosure Assembly Firmware

    € 42,95

    Members € 38,66

  • OWON VDS1022I 2-ch USB-oscilloscoop (25 MHz)

    OWON OWON VDS1022I 2-ch USB Oscilloscope (25 MHz)

    OWON VDS1022I 2-channel USB oscilloscope (25 MHz) is a oscilloscope for use with a computer. It is powered by USB and has a small size, making it easy to take it with you. The oscilloscope is very economical. It has a shielded USB connection, reducing interference and protecting the computer against over-voltage. The multi port on the scope can be used for external triggering, trigger out or Pass / Fail output. Features 25 MHz bandwidth, and max 1 GS/s real-time sample rate 10M record length Friendly UI: FFT, or X-Y, and waveform 2 views displayed on the same screen Multi-trigger option: edge, video, slope, pulse, and alternate USB isolation – less signal inference, more PC protection USB bus powering, and LAN remote control (optional) Ultra-thin body design, easy portability Specifications Bandwidth 25 MHz Channel 2+1 (multi) Sample Rate 100 MSa/s Horizontal Scale (s/div) 5 ns/div~100s/div, step by 1~2~5 Record Length 5K Max Input Voltage 400 V (PK - PK) (DC+AC, PK - PK) 40 V (PK - PK) (DC+AC, PK - PK) Vertical Resolution (A/D) 8 bits (2 channels simultaneously) Model VDS1022I Vertical Sensitivity 5 mV/div~5 V/div Trigger Type Edge, Pulse, Video, Slope, and Alternate Trigger Mode Auto, Normal, and Single Acquisition Mode Sample, Peak Detect, and Average Waveform Math +, -, ×, ÷, invert, FFT Communication Interface USB 2.0 (isolation) Multi-function Interface Signal Type Level Standard TTL Power Supply 5.0 V/1 A Power Consumption ≤2.5 W Dimensions (W × H × D) 170 x 120 x 18 mm Weight 0.26 kg Included 1x OWON VDS1022I oscilloscope 1x CD-ROM 1x Quick start guide 2x Oscilloscope probe 1x Probe tool 1x Power adapter 1x USB cable 1x Silicone case protectors 1x Power cable Downloads Datasheet User manual SCPI protocol USB driver

    € 119,95

    Members € 107,96

  • Pokit Meter – Portable Multimeter, Oscilloscope and Logger

    Pokit Meter - Portable Multimeter, Oscilloscope and Logger

    Pokit Meter is a revolutionary tool in the measurement industry. Its incredibly small size means you can put it on a keychain or in your pocket for unprecedented portability. Free yourself from the bench and take your creativity to new places! Pokit Meter harnesses the power of your smartphone, transforming it into an awesome measurement tool. The Pokit App measures a wide range of parameters, including voltage, current, resistance and temperature. It also provides continuity and a diode checker. Pokit Meter is ideal for low voltage electronics, automotive applications, home automation, and much more. Super Handy Retractable Leads: All-in-one multimeter, oscilloscope (one-time) and logger Highly Portable, it Fits in Your Pocket: Fits on your keychain so you can take it anywhere Wireless Connectivity: Connects to your phone via Bluetooth 60 V DC/42 V AC, 2 A Ultra-low Power and Long Battery Life: Suitable for low voltage electronics work (Arduino, Raspberry Pi), automotive applications etc. Full-Featured Multimeter Pokit Meter is a full-featured multimeter. The app brings all your favourite measurement modes into one seamless display. No knobs, no loose and bulky leads. Perfect for use in the home or on the go! True RMS measurement Auto ranging Voltage: 10 mV to 60 V DC, 42 V AC (RMS), ±1% Current: 1 mA to 2 A max, ±1% Resistance: 1 to 1M Ohm, ±5% Ambient temperature: 0°C to 60°C, ±1°C Continuity and diode polarity checker Digital Storage Oscilloscope An oscilloscope that small? Never before has this much freedom been brought to your fingertips in the realm of electronic test equipment. Pokit Meter’s oscilloscope captures detailed voltage and current waveforms for real-time display on your smartphone. Simply pinch and drag to zoom and pan. Long-press on the graph to set cursors and trace your signals. Pokit Meter also functions as a spectrum analyser. Switch into DFT mode to view your waveforms in the frequency domain. Sampling: 1 Msample/sec, 12-bit Voltage: 10 mV to 60 V DC, 42 V AC (RMS), ±1% Current: 1 mA to 2 A max, ±1% 1mS to 10s acquisition window Auto trigger or adjustable rising/falling trigger level Monitor Parameters Long Term Pokit Meter functions as a stand-alone data logger. It logs temperature, voltage, or current waveforms for periods of up to six months, without connection to a phone. Pokit Meter’s compact nature means it can be placed in tight or hard-to-reach spaces. Simply hook up your Pokit and walk away! 12-bit sampling Voltage: 10 mV to 60 V DC, 42 V AC (RMS), ±1% Current: 1 mA to 2 A max, ±1% 1 to 8000 points memory Up to 6 months logging

    € 139,95

    Members € 125,96

  • FNIRSI DSO152 Mini Oscilloscope (200 kHz)

    FNIRSI FNIRSI DSO152 Mini Oscilloscope (200 kHz)

    1 review

    The FNIRSI DSO152 is an extremely practical and cost-effective handheld oscilloscope with a real-time sampling rate of 2.5 MSa/s, a bandwidth of 200 kHz and complete trigger functions (single, normal and automatic). It can be used for both periodic analog signals and non-periodic digital signals and can measure voltages up to ±400 V. Equipped with an efficient one-key AUTO, it can display the measured waveform without cumbersome adjustments. It is equipped with a high-resolution 2.8-inch LCD screen with a resolution of 320x240 pixels and a built-in 1000 mAh high-quality lithium battery for up to 4 hours of operation. Specifications Sampling rate 2.5 MSa/s Bandwidth 200 kHz Vertical sensitivity 10 mV/DIV - 20 V/DIV (Progress according to the 1-2-5 way) Time base range 10µS/DIV - 50s/DIV (Progress according to the 1-2-5 way) Voltage range X1: ±40 V (Vpp: 80 V)X10: ±400 V (Vpp: 800 V) Trigger method Auto/Normal/Single Coupling method AC/DC Display 2.8' (320x240 pixels) USB charging 5 V/1 A Lithium battery capacity 1000 mAh Square wave calibration Frequency: 1K, Duty cycle: 50% Dimensions 99 x 68.3 x 19.5 mm Weight 100 g Included FNIRSI DSO152 Mini Oscilloscope Alligator clip probe USB cable Lanyard Manual Downloads Manual

    € 39,95

    Members € 35,96

  • JYE Tech WAVE2 2-ch Portable Oscilloscope DIY Kit

    JYE Tech JYE Tech WAVE2 2-ch Portable Oscilloscope DIY Kit

    Features No. of Channels: 2 Bandwidth: 0 – 200 KHz per channel Sensitivity range: 5 mV/DIV – 20 V/DIV (using x1 probe) Maximum input voltage: 50 Vpk (using x1 probe) Maximum real time sampling rate: 1 MS/s Time Base range 10 us/DIV – 500 s/DIV X-Y Display Feature: Yes Function Generator Capability: Built-in 0 – 20 KHz (sine) dual channel DDS function generator Display Resolution: 320 x 240 Color display Display Size: 2.4″ Touch Display Capability: Yes Battery powered and portable (battery not included in DIY Kit) Specifications General 2.4” 320x240 color display Touch panel operation Y-X mode available Built-in 2-channel DDS function generator Light weight and portable Vertical Number of Channel: 2 Analog Bandwidth: DC – 200 KHz Sensitivity: 5 mV/Div - 20 V/Div (with x1 probe) Sensitivity error: < 5% Resolution: 12-bit Input Impedance: 1 M ohm / 25 pF Maximum Input Voltage: 50 Vpk Coupling: DC, AC Horizontal Max Real-time Sampling Rate: 1 Msps (per channel) Timebase: 10 us/Div - 500 s/Div Record Length: 1024 points Trigger Trigger Modes: Auto, Normal, Single Trigger Types: Rising/falling edge Trigger Position: 1/2 of buffer size Trigger Source: Ch1, Ch2, External Maximum external trigger voltage: 15 V External trigger threshold: LVTTL Function Generator Number of channel: 2 Waveform type: Sine, Square, Saw-tooth, Stair Frequency range: DC – 20 KHz (Sine) Amplitude range: 0 – 3 V (peak value) Offset: 0 V or +3.3 V Duty Cycle: 0 – 100% Phase: -360 – 360 degree Power Supply Powered on 3.7 V Li-ion battery or USB Current consumption: ~30 0mA @ 3.7 – 5V Internal batter charger (optional) Automatic power off on battery Battery running time: Appr. 3 hrs (when fully charged) Other Features Y-X display mode On-screen measurement display Save / recall up to 4 captures Serial output of captured data Serial port format: LVTTL, 115200 bps, 8N1 Built-in 1 KHz/3.3 V test signal Physical Dimension: 115 x 72 x 30 mm Weight: 0.29 kg (excluding battery and probes)

    € 84,95

    Members € 76,46

  • FNIRSI 1013D 2-ch Tablet Oscilloscope (100 MHz)

    FNIRSI FNIRSI 1013D 2-ch Tablet Oscilloscope (100 MHz)

    The FNIRSI 1013D is a fully featured 2-channel tablet oscilloscope with a high-resolution 7-inch LCD screen (800 x 480 pixels). The oscilloscope has a real-time sampling rate of 1 GSa/s and an analog bandwidth of 100 MHz. With full trigger functions (single/normal/automatic), it can be used for periodic analog signals or non-periodic digital signals. The built-in high-voltage protection module can withstand a continuous voltage of up to 400 V. Features Intelligent anti-burn,1X can withstand up to 400 V withstand voltage. 100 MHz analog bandwidth @ 1 GSa/s sampling rate (1X = 5 MHz,10X = 100 MHz). Fully fit 7-inch 800 x 480 resolution color TFT LCD display with bright colors and high contrast. Capacitive touching screen, the same as the touching mode of modern mobile tablet, is not a resistive touching screen with ancient nail operation. High measurement voltage range, 1X can measure 0~40 V, 10X can measure 0~400 V,100X can measure 0~4000 V. Up to 12 parameters measurement: VPP, VP, Vmax, Vmin, Vavg, Vrms, Frequent, Duty+, Duty-, Time+, Time−, Period. Cursor measurement function, it is convenient to manually measure the period and frequency and voltage. Complete triggering function (single, normal, automatic). At any time, the waveform display (pause function) is frozen. Equipped with high efficiency One-button AUTO. One-button waveform storage and screenshot. Built-in 1 GB storage space, can store up to 1000 screenshots + 1000 sets of waveform data. Powerful waveform picture manager supports thumbnail browsing, viewing, detailed viewing, page turning, deletion and waveform zooming in, zooming out, moving, etc. Equipped with a USB interface, which can be connected to a computer to share its screenshots with the computer, which is convenient for secondary analysis. Lissajous figures graphic display function can be used to determine the amplitude, frequency, and phase contrast of two groups of signals. FFT display function, can analyze the spectral characteristics of the signal. Built-in 6000 mAh rechargeable lithium battery, fully charged for 4 hours of continuous use at the highest screen brightness. Memory compression technology, waveform refresh screen does not flicker. Screen brightness adjustment. Background grid brightness adjustment. Applications Electronic DIY Appliance repair Car repair Equipment debug Scientific research Product development Specifications Channels 2 LCD size 7 inch LCD resolution 800 x 480 Display technology TFT Bandwidth 100 Mhz Sampling rate 1 GSa/s Rise time <3nS Storage depth 240 Kbit Input resistance 1 MΩ Sensitivity 50 mV ~ 500 V Time base 50S ~ 10nS Trigger mode Single/Normal/Auto Trigger edge Rising/Falling Coupling AC/DC Highest test voltage 1X: 40 V, 10X: 400 V Cursor Position XY, Trigger Y Roll mode Yes One button AUTO Yes Waveform storage 1000 pictures + 1000 waveforms Waveform manager Yes Voltage accuracy ±2% Frequency precision ±0.01% high precision Parameter 12 kinds in total Battery 6000 mAh Lithium Standby 4 hours Extension USB export Power supply USB-C, 5 V @ 2 A/3 A/4 A Dimensions 184 x 124 x 50 mm Weight 650 g Included 1x FNIRSI 1013D 2-ch Tablet Oscilloscope 2x 100 MHz Probes (1X and 10X) 1x USB charger 1x USB cable 1x Manual Downloads Manual

    € 159,95

    Members € 143,96

  • Siglent SDS1104X-E 4-ch Oscilloscope (100 MHz)

    Siglent Siglent SDS1104X-E 4-ch Oscilloscope (100 MHz)

    The Siglent SDS1104X-E employs a new generation of SPO (Super Phosphor Oscilloscope) technology that provides excellent signal fidelity and performance. The system noise is also lower than similar products in the industry. It comes with a minimum vertical input range of 500 uV/div, an innovative digital trigger system with high sensitivity and low jitter, and a waveform capture rate of 400,000 frames/ sec (sequence mode).The SDS1104X-E also employs a 256-level intensity grading display function and a color temperature display mode not found in other models in this class. SIGLENT’s latest oscilloscopes offering supports multiple powerful triggering modes including serial bus triggering. Serial decoding is free and includes IIC, SPI, UART, CAN, and LIN. History waveform recording and sequential triggering enable extended waveform recording and analysis. Another powerful addition is the new 1 Mpt FFT math function that gives the SDS1104X-E very high frequency resolution when observing signal spectra.Features Intelligent trigger: Edge, Slope, Pulse Width, Window, Runt, Interval, Timeout (Dropout), and Pattern Free Serial bus triggering and decoding:IIC, SPI, UART, RS232, CAN, and LIN Video triggers and supports HDTV Low background noise and 500 μV / div to 10 V / div voltage scales 10 types of one-button shortcuts, supports Auto Setup, Default, Cursors, Measure, Roll, History, Display/Persist, Clear Sweep, Zoom and Print Segmented acquisition (Sequence) mode, dividing the maximum record length into multiple segments (up to 80,000), according to trigger conditions set by the user, with a very small dead time segment to capture the qualifying event. History waveform record (History) function, the maximum recorded waveform length is 80,000 frames Automatic measurement function on 38 parameters, supports Statistics, Gating measurement, Math measurement, History measurement and Ref measurement 1 Mpts FFT True measurement and math can use all 14 Mpts of memory Preset key can be customized for user settings or factory “defaults” Security Erase mode Highspeed hardware based Pass/ Fail function Large 7-inch TFT-LCD display with 800 * 480 resolution Multiple interface types: USB Host, USB Device (USB-TMC), LAN (VXI-11), Pass / Fail, Trigger Out Supports SCPI remote control commands Multi-language display and embedded help Browser control/onboard webpage for software free monitoring (4 channel models only) Included 1x Siglent SDS1104X-E Oscilloscope 4x 100 MHz probes 1x Guarantee Card 1x Power Cord 1x USB Cable 1x Quick Start Guide

    € 509,00

    Members € 458,10

  • OWON HDS242 2-ch Oscilloscope (40 MHz) + Multimeter

    OWON OWON HDS242 2-ch Oscilloscope (40 MHz) + Multimeter

    The HDS242 is a portable 2-in-1 multifunctional tester, which can be used as a 2-ch oscilloscope and multimeter. It features a high-contrast 3.5-inch color display suitable for outdoor facility maintenance, rapid on-site measurement, automobile maintenance, power detection. etc. Features Oscilloscope + Multimeter 3.5-inch high-resolution, high-contrast color LCD display – suitable for outdoor use 18650 lithium battery – can work continuously for up to 6 hours USB Type-C interface – support power bank and PC connection Self-calibration function SCPI supported – facilitate secondary development Specifications Oscilloscope Bandwidth 40 MHz Channels 2-ch Oscilloscope Sample Rate 250 MSa/s Acquisition Model Normal, Peak detect Record Length 8K Display 3.5-inch LCD Waveform Refresh Rate 10,000 wfrms/s Input Coupling DC, AC, and Ground Input Impedance 1 MΩ ±2%, in parallel with 16pF ±10pF Probe Attenuation Factors 1X, 10X, 100X, 1000X, 10000X Max. Input Voltage 400 V (DC+AC, PK-PK, 1MΩ input impedance) (10:1 probe attenuation) Bandwidth Limit (typical) 20 MHz Horizontal Scale 5ns/div - 1000s/div, step by 1 - 2 - 52ns/div - 1000s/div, step by 1 - 2 - 55ns/div - 1000s/div, step by 1 - 2 - 52ns/div - 1000s/div, step by 1 - 2 - 5 Vertical Sensitivity 10mV/div - 10V/div Vertical Resolution 8 bits Trigger Type Edge Trigger Modes Auto, Normal, single Automatic Measurement Frequency, Period, Amplitude, Max, Min, Mean, PK-PK Cursor Measurement ΔV, ΔT, ΔT & ΔV between cursors Multimeter Max. Resolution 20,000 counts Testing Mode Voltage, Current, Resistance, Capacitance, Diode, and Continuity test Input Impedance 10 MΩ Max Input Voltage AC: 750 V | DC: 1000 V Max Input Current DC: 10 A | AC: 10 A Diode 0-2 V Other Connectivity USB Type-C Dimensions 198 x 96 x 38 mm (7.68 x 3.74 x 1.5') Weight 600 g (without batteries) Included 1x OWON HDS242 Oscilloscope 1x Soft Bag 1x Probe 1x Power Cord 1x Probe Adjust 1x USB Cable 1x Power Adapter 1x Pair of Multimeter Probe Leads (red one and black one) 1x Pair of Oscilloscope Probe Leads (BNC to Alligator Clip) 1x User Manual (English) Downloads User Manual for HDS200 Series SCPI Protocol for HDS200 Series Quick Guide for HDS200 Series PC Software for OWON HDS200 Series

    € 129,95

    Members € 116,96

  • PicoScope 2204A USB-oscilloscoop (10 MHz)

    Pico Technology PicoScope 2204A USB Oscilloscope (10 MHz)

    Out of stock

    You can use your PicoScope 2000 Series as an advanced oscilloscope, spectrum analyzer, function generator, arbitrary waveform generator and protocol decoder out of the box. Mixed signal models also add a 16 channel logic analyzer. A complete electronics lab in one compact, low-cost, USB-powered unit. The PicoScope 2000A models deliver unbeatable value for money and are ideal for education, hobby and field service use. In the lab the low cost allows one scope per person rather than having to share. High-end oscilloscope At the heart of every PicoScope 2000 is an advanced oscilloscope which offers everything you would expect and much more besides: 10,000 waveform circular buffer Up to 80,000 waveforms per second update rate Mask limit testing Advanced math & filtering Measurements with statistics Advanced digital triggering Resolution enhancement to 12 bits Logic analyzer / mixed signal ability The PicoScope 2000 Series includes mixed signal models that include 16 digital inputs so that you can view digital and analog signals simultaneously.The digital inputs can be displayed individually or in named groups with binary, decimal or hexadecimal values shown in a bus-style display. A separate logic threshold from -5 V to +5 V can be defined for each 8-bit input port. The digital trigger can be activated by any bit pattern combined with an optional transition on any input. Advanced logic triggers can be set on either the analog or digital input channels, or both to enable complex mixed-signal triggering.The digital inputs bring extra power to the serial decoding options. You can decode serial data on all analog and digital channels simultaneously, giving you up to 18 channels of data. You can for example decode multiple SPI, I²C, CAN bus, LIN bus and FlexRay signals all at the same time!) Features 2 channel 6 instruments in one Ultra-compact design 10 MHz bandwidth 8 kS buffer memory Sample rate: 100 MS/s Decode 15 serial protocols as standard USB connected and powered Windows, Linux and Mac software Included 1x PicoScope 2204A oscilloscope 2x Oscilloscope probes 1x USB cable 1x Quick start guide Downloads Manuals & Software

    Out of stock

    € 229,00

    Members € 206,10

  • OWON SDS1022 2-ch Oscilloscope (20 MHz)

    OWON OWON SDS1022 2-ch Oscilloscope (20 MHz)

    The OWON SDS1022 is a competitively priced oscilloscope with a sample rate of 1 GSa/s and a bandwidth of 20 MHz. Furthermore, with this oscilloscope you have 2 channels at your disposal and it is possible to store 10 K points per measurement. There is a USB connector on the back for exporting measurement results to the PC, and a USB port on the front for exporting to a USB memory stick.Features Bandwidth: 20 MHz 2-Channels Sample rate: 100 MS/s Ultra-thin body 7' high resolution LCD SCPI and LabVIEW supported Specifications Bandwidth 20 MHz Sample Rate 100 MS/s Horizontal Scale (s/div) 5 ns/div - 1000 s/div, step by 1 - 2 - 5 Channel 2 Display 7' color LCD, 800 x 480 pixels Input Coupling DC, AC and GND Vertical Resolution (A/D) 8 bits (2 channels simultaneously) Vertical Sensitivity 5 mV/div - 5 V/div (at input) Trigger Type Edge, Video Trigger Mode Auto, Normal, and Single Waveform Math +, -, x, ÷, invert, FFT Fuse 2 A, T class, 250 V Dimension (W x H x D) 301 x 152 x 70 mm Device Weight 1.10 kg Downloads USB Driver PC Software

    € 199,95

    Members € 179,96

  • Last stock! JYE Tech DSO Shell 150 Oscilloscope DIY Kit

    JYE Tech JYE Tech DSO Shell 150 Oscilloscope DIY Kit

    2 in stock

    Compared to DSO138, the new DSO Shell has similar bandwidth with significant improvements in structure, mechanical, and operation. The sensitivity has been extended in both directions : 5mV/div – 20V/div (DSO138: 10mV/div – 5V/div.Display and MCU are now mounted on the same mainboard to avoid inter-board pin-headers.For better separation between analog and digital circuits, the analog channel is on a separated board. Without the analog portion, the mainboard is actually a general-purpose control board. The mainboard is fully installed (except a few through-hole components), and factory tested.DSO Shell comes with an easy to modify enclosure. Rotary encoder makes parameter adjustment quick and easy.Power supply (not included): 9V (< 10V!) standard 5.5mm/2.1mm DC plug or 2-pin connector (0.1' pitch)Adequate soldering and troubleshooting skills required. Mainboard: 109-15000-00E or 109-15000-00E1 (Performance & assembly are identical) Analog board: 109-15001-00E or 109-15001-00F (Performance & assembly are identical) Product Documents and firmware: Users Manual (for 109-15001-00C analog board) Users Manual (for 109-15001-00E analog board) Schematic Main board schematic Analog board schematic Firmware How to Use the DSO150 Library Source code FAQ, Tips, and Troubleshooting Specifications Vertical Number of Channels 1 Analog Bandwidth 0 - 200 kHz Sensitivity 5 mV/Div - 20 V/Div Sensitivity error < 5 % Resolution 12-bit Input Impedance 1 MΩ Maximum Input voltage 50 Vpk Coupling DC, AC, GND Horizontal Max Real-time Sampling Rate 1 Msps Timebase 10 µs/Div - 500 s/Div Record Length 1024 Trigger Trigger Modes Auto, Normal, Single Trigger Types Rising / falling edge Trigger Position 1 / 2 of buffer size fixed Display 2.4-inch color TFT LCD 320 x 240 px Power Supply 9 V DC (8 - 10 V acceptable) Supply Current 120 mA @ 9 V Physical Dimensions 115 x 75 x 22 mm Weight 100 g without cables & power supply

    2 in stock

    € 44,95

    Members € 40,46

  •  -25% JYE Tech DSO Coral 112A Oscilloscope

    JYE Tech JYE Tech DSO Coral 112A Oscilloscope

    DSO Coral (112A) is an upgraded model of DSO112 with re-designed schematic and PCB. Due to the new design this oscilloscope becomes more accurate and reliable. As high as 2 mV/div sensitivity and ultra low background noise made the device particularly useful for measuring weak signals. Up to 24 presets with customizable titles allow setups be retrieved in seconds. While keeping all performance of DSO112 this new model brings in the following improvements: Maximum sensitivity was increased to 2 mV/div (older version is 5 mV/div) with lower background noises. Fixed the vertical position mismatch problem found in the older model. Save/recall up to 24 parameter presets. This allows quick setup for frequently performed measurements. Preset titles can be customized for easy remembering and identifying. Expanded and improved on-screen measurement displays which include frequency, Vmax, Vmin, Vavr, Vpp, and Vrms. Added external trigger feature. Provided a two-way serial control interface which can output data/measurements and receive commands. This will make the device suitable for integration to customer applications. Replaced out-dated miniUSB connector with more popular microUSB connector. Enclosure strength enhanced. CE certified Specifications Vertical Number of Channel: 1 Analog Bandwidth: 0 - 2MHz Sensitivity: 2 mV/Div - 20 V/Div Sensitivity error: <5% Resolution: 8-bit Input Impedance: 1M ohm Maximum Input voltage: 50 Vpk Coupling: DC, AC, GND Voltage measurement cursors available Auto-measurement of Vavr and Vpp Horizontal Max Real-time Sampling Rate: 5 Msps Timebase: 1 us/Div - 50 s/Div Record Length: 512 and 1024 variable Time measurement cursors available Trigger Trigger Modes: Auto, Normal, Single Trigger Types: Rising/falling edge Trigger Position: 1/8, 1/4, 1/2, 3/4, and 7/8 of buffer size Trigger Source: internal, external External trigger voltage range: 0 - 15 V Test Signal Generator 7 frequencies from 1 Hz to 1 MHz selectable. Amplitude 3.3 V fixed Other Features Save captured waveform to EEPROM and recall after power outage Save/recall up to 24 presets Serial data/control interface USB firmware upgrade Display 2.4' color TFT LCD with 320 x 240 resolution Power Supply 3.7 V Li-ion battery/USB Supply Current: 300 mA @ 3.7 V(LCD backlight ON). Built-in charger Physical Dimension: 80 x 70 x 18 mm Weight: 85 gram (not including cables) Included 1x DSO112A (Battery included) 1x Standard BNC probe 2x MCX-clip cables 1x USB cable Quick User Guide Downloads Quick User Guide (Rev. 02) User Manual (Rev. 02) Firmware

    € 79,95€ 59,95

    Members identical

  • Last stock! Siglent SDS1104X-U 4-ch Oscilloscope (100 MHz)

    Siglent Siglent SDS1104X-U 4-ch Oscilloscope (100 MHz)

    2 in stock

    The SDS1000X-U series employs SPO (Super Phosphor Oscilloscope) technology that provides excellent signal fidelity and performance. It comes with an innovative digital trigger system with high sensitivity and low jitter, and a waveform capture rate of 400,000 frames/sec (sequence mode). The SDS1000X U also employs a 256 level intensity grading display function and a color temperature display mode not found in other models in this class.Another powerful addition is the new 128 k point FFT math function that gives the SDS1000X-U a very high-frequency resolution when observing signal spectra. SDS1000X-U also supports searching and navigating. The features and performance of SIGLENT’s new SDS1000X-U cannot be matched anywhere else in this price class.Features 100 MHz bandwidth Real-time sampling rate up to 1 GSa/s The newest generation of SPO technology Waveform capture rates up to 100,000 wfm/s (normal mode) and 400,000 wfm/s (sequence mode) Supports 256-level intensity grading and color temperature display modes Record length up to 14 Mpts Digital trigger system Intelligent trigger: Edge, Slope, Pulse Width, Window, Runt, Interval, Time out (Dropout), Pattern Serial bus triggering and decoding (Standard), supports protocols I²C, SPI, UART, CAN, LIN Video trigger, supports HDTV 10 types of one-button shortcuts, supports Auto Setup, Default, Cursors, Measure, Roll, History, Display/Persist, Clear Sweep, Zoom and Print Segmented acquisition (Sequence) mode, divides the maximum record length into multiple segments (up to 80,000), according to trigger conditions set by the user Automatic measurement function for 38 parameters as well as Measurement Statistics, Zoom, Gating, Math, History and Reference functions History waveform record (History) function (maximum recorded waveform length is 80,000 frames) 128 k pts FFT, supports Peaks and Markers Math functions (FFT, addition, subtraction, multiplication, division, integration, differential, square root) Large 7 inch TFT LCD display with 800 x 480 resolution

    2 in stock

    € 429,00

    Members identical

  • Last stock! Siglent SDS1202X-E 2-ch Oscilloscope (200 MHz)

    Siglent Siglent SDS1202X-E 2-ch Oscilloscope (200 MHz)

    2 in stock

    SIGLENT’s SDS1000X-E Series Super Phosphor Oscilloscope is available in one bandwidth, 200 MHz. It has a maximum sample rate of 1 GSa/s and a standard record length of 1 Mpts. For ease-of-use, the most commonly used functions can be accessed with its user-friendly front panel design.The SDS1000X-E series employs a new generation of SPO (Super Phosphor Oscilloscope) technology that provides excellent signal fidelity and performance. The system noise is also lower than similar products in the industry. It comes with a minimum vertical input range of 500 uV/div, an innovative digital trigger system with high sensitivity and low jitter, and a waveform capture rate of 400,000 frames/ sec (sequence mode).The SDS1000X-E also employs a 256-level intensity grading display function and a color temperature display mode not found in other models in this class. Siglent’s latest oscilloscopes offering supportsmultiple powerful triggering modes including serial bus triggering. Decoding is standard configuration including IIC,SPI,UART,CAN,LIN. History waveform recording and sequential triggering enable extended waveform recording and analysis.Another powerful addition is the new 1 million points FFT math function that gives the SDS1000X-E very high frequency resolution when observing signal spectra. The new design also includes a hardware co-processor that delivers measurements quickly and accurately.The features and performance of Siglent’s new SDS1000X-E cannot be matched anywhere else in this price class.Siglent Oscilloscope SDS1202X-E Bandwidth 200 MHz Channels 2CH+1EXT Real time sampling rate 1 GSa/s Memory depth 7 Mpts/CH (Dual-Channel); 14 Mpts/CH (Single-Channel) Waveform Capture Rate (Max.) 100,000 wfm/s (normal mode); 400,000 wfm/s (sequence mode) Serial Trigger (Standard) IIC, SPI, UART/RS232, CAN, LIN Decode Type (Standard) IIC, SPI, UART/RS232, CAN, LIN Trigger Type Edge, Slope, Pulse Width, Window, Runt, Interval, Dropout, Pattern, Video Probe (Std) 2 pcs passive probe PP215 Display 7 inch TFT-LCD (800x480) Weight Without package 2.5 kg; with package 3.5 kg

    2 in stock

    € 439,00

    Members € 395,10

  • Last stock! JYE Tech DSO068 Oscilloscope DIY Kit

    JYE Tech JYE Tech DSO068 Oscilloscope DIY Kit

    2 in stock

    This kit is particularly suitable for educational use. It uses through-hole components as much as possible. This eases off the requirement of assembly skills and at the same time allows deeper user involvement. It is a great tool for college students. Most importantly it brings in the freedom for users to test, modify, experiment, and even design their own projects. And this means more fun! More over, DSO 068 is not just a kit for training but also a practical tool for everyday use. Parameter setting is simply, straightforward, and quick. Mode switch and utilities are driven by menu. Absolutely no complicate navigation. It was designed on the base of DSO 062 kit and comprises many enhancements in hardware and firmware: Higher sensitivity (10 mV/div vs 100 mV/div) Wider analog bandwidth (3 MHz vs 1 MHz) Larger capture buffer (1024 points vs 256 points) Variable trigger position (1% - 100%) with indicator Test signal generator with variable frequency and amplitude USB connection Upload of captured raw data as CSV file (Example) Work as USB scope (with jyeLab) and data logger (8 channels, 10-bit resolution) Higher sensitivity (0.2 Vpp vs 3 Vpp) in built-in frequecy meter Battery/USB powered Fully enclosured Silicone pushbuttons and rotary encoder Major parts Main circuit board with pre-soldered ICs and a few SMD parts. Board is pre-tested and MCUs on board are pre-programmed. 128 x 64 graphic dot-matrix LCD module. Step-up voltage converter board (JYE116). It boosts battery voltage to 5 V from as low as 2 V. Voltage inverter board (JYE120). It generates -5 V from +5 V with current capacity up to 200 mA. On/Off switch board (JYE117). This is the power switch of instrument. [optional] Li-ion battery charger board (JYE118). It includes the USB/Battery power switch circuit. [optional] USB-Uart converter board (JYE119). This bridges the scope to USB host. [optional] Professional 20 MHz probe with selectable 1X/10X attenuation. Enclosure set including stand, switch caps, etc. All through-hole components, mechanical parts, accessories (battery not included) and Assembly Guide and User Manual. Source codes of student version firmware are also provided for downloading. They are simplified from full version to help users to understand how the oscilloscope works. The sampling rate of student version is limited to 500 Sa/s - 100 KSa/s with no other features. Important Notes Adequate soldering skills and troubleshooting skills to assemble the DSO138 kit are required. Each mainboard has been tested to ensure no short or open on MCU soldering. Each LCD board is also tested to verify soldering is good and display is functional. The other components are provided with good quality at our best knowledge. They are not tested.

    2 in stock

    € 79,95

    Members € 71,96

What is an oscilloscope? What are the advantages of a digital oscilloscope?

Oscilloscopes are electronic instruments that allow us to visualize different signals as a function of time on a 2D plot. Oscilloscopes come in a variety of sizes and can allow anyone with an interest in electronics – from students to makers to craftsmen – to discover how waveforms vary as a circuit is adjusted.

A digital oscilloscope is a useful tool for analyzing the response of a circuit, and it allows us to see on the screen what our eyes cannot see. With a digital oscilloscope you can test and debug the analog outputs of sensors, and you can verify and quickly analyze various parameters such as amplitude, frequency, and distortion.

When you look at an oscilloscope, you see the screen and the buttons for the vertical settings, the horizontal settings and the triggering. The display is usually a cathode ray tube (CRT), which is used not only for oscilloscopes, but also for other applications such as television and computer monitors. Its function is to convert an electrical signal into a visual representation.

What types of oscilloscopes are there? And what are the differences?

Today, digital oscilloscopes are the most popular type. An analog oscilloscope displays the waveform in its original form, while a digital oscilloscope samples the original analog waveform and converts the result into digital numbers, then stores it in digital format.

Another important type of oscilloscope is the USB oscilloscope. It is operated via a computer or tablet using a USB port. The USB oscilloscope has one or more analog channels, possibly digital channels, and buttons or switches for operation.

USB oscilloscopes are less expensive than traditional ones because the graphics are provided by the host PC. An A/D converter and a USB interface are all that is needed for a USB oscilloscope. Furthermore, USB oscilloscopes are usually small and can be used in places where access is limited. Moreover, they are a great solution for applications that require flexibility, as they are a great portable option.

An automotive oscilloscope is a necessary instrument for detecting malfunctions in all kinds of electronic components in vehicles. Moreover, it is often used by car technicians for car diagnostics. The only difference between an automotive oscilloscope and a digital oscilloscope is that it offers additional capabilities for testing and diagnosis.

What is a PicoScope?

PicoScope is computer software that allows Pico Technology oscilloscopes to measure real-time signals. A PicoScope PC oscilloscope is an application for measuring and testing all electrical components and circuits in vehicles. Your PC can become a powerful diagnostic tool with the help of a PicoScope.

Buy an oscilloscope. What does Elektor have to offer?

An oscilloscope is an essential tool for anyone who works with electronic circuits. It is useful if you want to get to know the behavior of your project and detect errors in your circuits.

Elektor offers a wide choice of oscilloscopes in various sizes and with varying specifications, including bandwidth, vertical resolution, and horizontal scale. In addition, we offer a selection of oscilloscopes that are very suitable for a number of areas of interest. Some of the most popular products Elektor sells are the PicoScope 2204A USB Oscilloscope and the SmartScope USB oscilloscope, which provide a complete electronics lab in one compact, low-cost, USB-powered device. The affordable PicoScope and SmartScope models are ideal for education, hobby and field use.

What accessories are there for oscilloscopes?

Digital oscilloscopes usually come with a set of probes. In addition to scopes, Elektor sells a range of related products, including cables and DIY kits.

Why should you buy an oscilloscope from Elektor?

Electrical engineers, makers and electronics enthusiasts turn to Elektor for affordable, high-quality test and measurement equipment such as oscilloscopes. We stock a range of oscilloscopes – from portable handheld devices to high-end desktop solutions – to meet the different needs of a wide audience.
