Measuring Tools

303 products


  • Makerfabs Jumper Wires Combo Pack

    Makerfabs Makerfabs Jumper Wires Combo Pack

    With these jumper wires (length: 20 cm) you can connect a Raspberry Pi or an Arduino with breadboards. Each cable consists of 40 individual wires/pins which can also be separated. Included 1x 40-pins female to female 1x 40-pins male to male 1x 40-pins male to female

    € 6,95

    Members € 6,26

  •  -21% FNIRSI 2C23T (3-in-1) 2-ch Oscilloscope (10 MHz) + Multimeter + Signal Generator

    FNIRI FNIRSI 2C23T (3-in-1) 2-ch Oscilloscope (10 MHz) + Multimeter + Signal Generator

    Pre-order

    The FNIRSI 2C23T is a fully functional, highly practical 3-in-1 dual channel digital oscilloscope with a high resolution 2.8-inch LCD display (320 x 240 pixels) designed for the maintenance and development industry. This device is equipped with 3 main functions: oscilloscope, multimeter and signal generator. The oscilloscope has an FPGA+MCU+ADC hardware architecture with a sampling rate of 50 MS/s, an analog bandwidth of 10 MHz and a built-in high-voltage protection module that supports the measurement of peak voltages of ±400 V maximum. The multimeter has a 4-digit 10000-point RMS value and supports AC/DC voltage and current measurements, as well as capacitance, resistance, diode, on/off and other measurement functions. Equipped with a built-in DDS function signal generator, it can output 7 kinds of function signals, with a maximum output of 2 MHz for all signals and a step of 1 Hz; the output frequency, amplitude and duty cycle are adjustable. The built-in 3000 mAh rechargeable lithium battery achieves a standby time of up to 6 hours. Features 2-ch oscilloscope 10 MHz bandwidth 50 MS/s real-time sampling rate 7 signal waveforms 10000 counts 2.8' HD color display (320 x 240 pixels) Dimensions: 167 x 89 x 35 mm Weight: 300 g Specifications Oscilloscope Dual channel, 2x 10 MHz bandwidth, 50 MS/s real-time sampling rate Maximum measured voltage: ±400 V FPGA+ADC+MCU high-performance hardware architecture, capturing waveform details without loss Equipped with complete triggering functions (auto, single, normal) Equipped with efficient automatic adjustment, the measured waveform can be displayed without complicated adjustment Save waveform screenshots, supports exporting images to a computer, facilitate secondary waveform analysis Multimeter 4-bit integer 9999 counting True RMS measurement Identification of voltage, current, capacitance, resistance, diode, on/off, and zero live wire Maximum input voltage: AC 750 V, DC 1000 V Automatic range, intelligent anti burning Data retention, color screen digital display Signal Generator 7 signal waveforms: sine wave, square wave, triangular wave, full wave, half wave, noise wave, DC Output frequency: 1 Hz-2 MHz Output amplituade: 0.1-3.3 V Output duty cycle: 0-100% Included 1x FNIRSI 2C23T (3-in-1) 2-ch Oscilloscope 1x P6100 oscilloscope probes (10X) 1x Multimeter probe 1x Crocodile clip probe 1x USB-C charging cable 1x Original Manual by FNIRSI (English, German, Spanish, Portuguese, Russian, Chinese) 1x Elektor Manual (English, French, German, Dutch) Downloads Manual Firmware V2.0.2

    Pre-order

    € 94,95€ 74,95

    Members identical

  • FNIRSI DPOX180H (2-in-1) 2-ch Digital Phosphor Oscilloscope (180 MHz) & Signal Generator

    FNIRSI FNIRSI DPOX180H (2-in-1) 2-ch Digital Phosphor Oscilloscope (180 MHz) & Signal Generator

    1 review

    Out of stock

    The FNIRSI DPOX180H is a cost-effective handheld dual-channel digital phosphor oscilloscope and signal generator. The oscilloscope has a real-time sampling rate of 500 MS/s and an analog bandwidth of 180 MHz. The measurement results are displayed on the high-contrast 2.8-inch IPS full-view LCD screen with digital fluorescence technology. Features 2-ch handheld oscilloscope & DDS signal generator 180 MHz bandwidth 500 MS/s sampling rate 20 MHz signal generator Innovative digital trigger system Cursor measurement function 5 mV sensitivity 50000 wfm/s waveform refresh rate 2.8' IPS full-vision high-definition display Built-in 4.2 V/3000 mAh lithium battery Automatic shutdown setting High-voltage anti-burning protection Specifications Nummer of channels 2 Analog bandwidth 180 MHz Maximum sampling rate 500 MS/s Input coupling DC/AC Rise time 2.5s Storage depth 120 Kpts Input impedance 1 MQ-18 PF Vertical sensitivity 5 mV-10 V (1X) Time base range 5 nS~50 S DC accuracy ±2% Time accuracy +0.01% Trigger detection Digital trigger Trigger mode Auto/Single/Normal Trigger edge Rising/Falling Measurement range 40 mV~80 V (1X) Screenshot storage 90 Capture signal 500 Screen size 2.8 inch Screen resolution 320 x 240 Display technology IPS full view Expansion interface USB transmission interface Auto power off 5 minutes - 2 hours Firmware upgrade Supported iso image upgrade Charging requirements 5 V/2 A Battery capacity 3000 mAh Standby time 3.5 hours at full charge Signal Generator 14 standard function signals Waveform storage 250 groups Parameter measurement 12 kinds Dimensions 135 x 90 x 40 mm Digital Phosphor Oscilloscope FNIRSI DPOX180H Oscilloscope uses the latest digital phosphor technology to overcome the traditional oscilloscope due to noise caused by the waveform burr feeling. Color temperature display function can more clearly see the distribution of the signal, probability characteristics and the rise and fall time of the step signal fast and slow. X-Y mode with digital phosphor technology for comparison of amplitude, frequency and phase of two groups of signals. DDS Function Signal Generator Built-in 20 MHz DDS function signal generator, with 14 kinds of standard function signals, output amplitude fixed at 1 VPP, sine wave frequency of 20 MHz, other waveform frequency of 10 MHz, adjustable frequency step of 1 Hz. Contains the original chopping technology, intercept part of the oscilloscope measurement of complex signals as the output signal of the signal generator, than the traditional signal generator hand-drawn signal more objective and realistic. Included 1x FNIRSI DPOX180H phosphor oscilloscope 2x Probes (200 MHz) 1x USB power supply 1x USB cable 1x Manual Downloads Manual Firmware V40

    Out of stock

    € 159,95

    Members € 143,96

  •  -17% OWON XDM1141 Multimeter

    OWON OWON XDM1141 Multimeter

    The OWON XDM1141 is a fast, high-precision digital True RMS benchtop multimeter with a high-resolution 3.5-inch LCD and 50,000 counts. Its DC voltage accuracy is up to 0.05% and it can measure up to 65 values per second. Features 3.5' high-resolution LCD (480x320 pixels) 55000 counts, DC voltage accuracy up to 0.05% Up to 65 readings per second Dual line display supported Trend analysis accessible in chart mode AC True RMS measurements (bandwidth: 20 Hz – 1 kHz) SCPI support: Remote control the multimeter through PC software via USB port Data record function, you can record the measured data into internal memory, and then read and process the recorded data with your computer. Specifications Measurement Range Resolution Accuracy DC Voltage 50.000 mV 0.001 mV 0.1% +10 500.00 mV 0.01 mV 0.05% +5 5.0000 V 0.0001 V 0.05% +5 50.000 V 0.001 V 0.05% +5 500.00 V 0.01 V 0.1% +5 1000.0 V 0.1 V 0.1% +10 AC Voltage 500 mV~750 V 20 Hz~45 Hz 1% +30 45 Hz~65 Hz 0.5% +30 65 Hz~1 KHz 0.7% +30 DC Current 500 uA 0.01 uA 0.15% +20 5000 uA 0.1 uA 0.15% +10 50 mA 0.001 mA 0.15% +20 500 mA 0.01 mA 0.15% +10 5 A 0.0001 A 0.5% +10 10 A 0.001 A 0.5% +10 AC Current 500 uA~500 mA 20 Hz~1 KHz 0.5% +20 5 A-10 A 1.5% +20 Resistance 500 Ω 0.01 Ω 0.15% +10 5 KΩ 0.0001 KΩ 0.15% +5 50 KΩ 0.001 KΩ 0.15% +5 500 KΩ 0.01 KΩ 0.15% +5 5 MΩ 0.0001 MΩ 0.3% +5 50 MΩ 0.001 MΩ 1% +10 Frequency 10.000 Hz~60 MHz / ±(0.2% +10) Capacitance 50 nF~500 uF / 2.5% +10 5 mF~50 mF 5% +10 Diode 3.0000 V 0.0001 V / Continuity 1000 Ω 0.1 Ω Adjustable threshold Temperature K type, PT100 Max Display 55,000 counts Data-logging Function Logging Duration 15ms~9999.999s Logging Length 1,000 points Display 3.5' TFT LCD (480x320 pixels) Dimensions 200 x 88 x 150 mm Weight approx. 0.5 kg Included 1x OWON XDM1141 Multimeter 1x Power cord 2x Test leads 1x Fuse 1x USB cable 1x Manual Downloads Programming Manual PC Software

    € 144,95€ 119,95

    Members identical

  • Peak Atlas DCA75 Pro – Intelligente halfgeleider-analyser

    Peak Peak Atlas DCA75 Pro Advanced Semiconductor Analyser

    The DCA75 Pro is a great instrument that combines ease-of-use with amazing features. It can automatically identify a huge range of semiconductors, automatically identify pinouts and measure detailed parameters. Features Built-in graphics display (now backlit) to show detailed schematic of the component you're testing as well as pinout and measurement data. USB connectivity to allow curve tracing, data storage/retrieval and device matching on your Windows PC (Windows 7 and higher). Single internal AAA alkaline cell for standalone operation. Component Support Bipolar transistors (NPN/PNP inc Silicon/Germanium) Darlington transistors (NPN/PNP) Enhancement mode MOSFETs (N-Ch and P-Ch) Depletion mode MOSFETs (N-Ch and P-Ch) Junction FETs (N-Ch and P-Ch). Both symmetrical and asymmetrical types Enhancement IGBTs (N-Ch and P-Ch) Diodes and diode networks (2 and 3 lead types) Zener diodes (up to about 9 V) Voltage regulators (up to about 8 V) LEDs and bi-colour LEDs (2 lead and 3 lead types) Low power sensitive Triacs and Thyristors (<10 mA trigger and hold) Measurements BJT current gain (hFE) BJT base emitter voltage (Vbe) BJT collector leakage current MOSFET on and off gate threshold voltages MOSFET transconductance JFET pinch-off voltage JFET transconductance JFET IDSS (drain current for Vgs=0) IGBT on and off gate threshold voltages IGBT transconductance Voltage regulator output voltage Voltage regulator quiescent current consumption Voltage regulator drop-out voltage Zener voltage Diode forward voltage drop Specifications Analyser type Semiconductor components Component detection Automatic Pinout detection Automatic, connect any way round Display type Graphic LCD (now backlit) Interface type USB for optional PC connection PC functions Curve tracing (Windows 7 and higher) Software Included on USB drive for Windows 7 and higher Battery Single AAA cell (supplied) Included DCA75 Semiconductor Component Analyser PC software on a USB Flash Drive for Windows 11, 10, 8, 7, XP Micro USB cable Fitted universal premium hook probes AAA Alkaline battery Downloads Datasheet (EN) User Guide (EN) User Guide (FR) User Guide (DE) User Guide (IT) Software Installation Guide (EN) Software and Firmware Package

    € 169,95

    Members € 152,96

  • JOY-iT RD6006 DC Power Supply (360 W)

    JOY-iT JOY-iT RD6006 DC Power Supply (360 W)

    The JT-RD6006 is a buck step down direct voltage power supply unit which can be used in different operation modes (f.i. Constant current or constant voltage mode, etc.). Due to the keypad and a push and rotary encoder, the operation of the power supply unit is very comfortable. In addition, you can easily save and reload up to nine settings using the keypad. The high-resolution 2.4-inch colour display clearly shows all important information. The USB interface and an optional wireless network interface enable the device to be operated via PC or with an app from mobile devices. It has also diverse protection and limitation functions like f. i. Constant voltage, constant current operation mode or Overvoltage and Overcurrent protection and switchable fuses on the board (back side). Features Battery charging function Value input comfortable via keypad Overcurrent /overvoltage protection adjustable Specifications Input Voltage 6 - 70 V Output Voltage 0 - 60 V Output Current 0 - 6 A Output Power 0 - 360 W Voltage Resolution 0.01 V Current Resolution 0.001 A Capacity Measurement Range 0 - 9999.99 Ah Energy Measurement Range 0 - 9999.99 Wh Residual Ripple 100 mV(pp) (at maximal capacity) Display 2.4 Inch LCD Working Temperature Range -10 to 40 °C Dimensions 167 x 81 x 65 mm Weight 607 g Downloads Datasheet JT-RD6006 Manual JT-RD6006 PC Software Windows driver Mac driver Linux driver

    € 94,95

    Members € 85,46

  •  -25% Temperature-controlled Soldering Station ZD-8961-A

    Zhongdi Temperature-controlled Soldering Station ZD-8961-A

    This temperature-controlled digital soldering station with adjustable temperature range from 160°C to 480°C is an affordable and reliable tool for all kinds of soldering work in the (home) laboratory. Thanks to the high-quality coated heating element, the desired soldering temperature (Celsius or Fahrenheit) is quickly reached and shown on the LED display. Features A temperature controlled soldering station with adjustable temperature range from 160°C to 480°C (320°F to 896°F). A two-line LED readout simultaneously displays temperature setting and actual temperature. Gloss finish pleasing to the eye. Compact and lightweight soldering iron with silicone cord. A user-friendly soldering iron handle with a foam sleeve. Easier way to achieve °C/°F conversion with the asterisk button. Specifications Power 25 W (max. 50 W) Display LED Temperature 160°C to 480°C (320°F to 896°F) Temperature deviation ±5% Grounded Yes Heating rate Melt solder within 20s Withstand voltage 1500/1MA Input voltage AC 220-240 V (50 Hz) Output voltage 24 V Included Soldering station ZD-8961-A Solderin iron stand Soldering iron with soldering tip N8-1 Cleaning sponge Cleaning ball Power cord (EU)

    € 79,95€ 59,95

    Members identical

  •  -33% Anet 4540 Desktop CNC-freesmachine

    Anet Anet 4540 Desktop CNC Router Machine

    With this CNC milling machine, you can easily and quickly engrave, cut and drill with the highest precision. This powerful and efficient 3-axis CNC router machine is great for hobbyists, makers, DIY enthusiasts and pro engineers. The easy-to-use machine is ideal for cutting and engraving wood, MDF, metal, plastic, acrylic, leather, PCB and other materials. Features 3-axis CNC controller Engraving, cutting and drilling Large working area (430 x 390 x 90 mm) 500 W high-power spindle GRBL control Easy to assemble (main components are already pre-assembled) Specifications Working area 430 x 390 x 90 mm (16.93 x 15.39 x 3.54') Power supply 48 V/10.4 A Power of spindle motor 500 W Speed of spindle motor 11,000 rpm Stepping motor 42 x 48 mm Limit switch X, Y, Z (both ends) Material 4040 Aluminum Emergency stop switch Yes Offline controller Yes Software GRBLcontrol (Candle), other GRBL-compatible Software Other feature Laser Engraving (laser module is not included) Supported systems Windows XP/7/8/10 Dimensions 650 x 532 x 320 mm (25.59 x 20.94 x 12.60') Weight 11.6 kg (25.6 pounds)

    € 899,00€ 599,00

    Members identical

  • FNIRSI 1014D (2-in-1) 2-ch Oscilloscope (100 MHz) & Signal Generator

    FNIRSI FNIRSI 1014D (2-in-1) 2-ch Oscilloscope (100 MHz) & Signal Generator

    The FNIRSI 1014D is a 2-in-1 oscilloscope and signal generator with comprehensive functions and high practicality. It is a cost-effective 2-channel desktop oscilloscope for the maintenance industry and R&D industry. The oscilloscope has a real-time sampling rate of 1 GSa/s and an analog bandwidth of 100 MHz. The built-in DDS signal generator supports 12 types of function signals. Specifications Channels 2 Display size 7 inch LCD LCD resolution 800 x 480 Bandwidth 100 MHz Sampling rate 1 GSa/s Rise time <3nS Storage depth 240 Kbit Input resistance 1 MΩ Sensitivity 50 mV ~ 500 V Time base 50s ~ 10nS Trigger mode Single/Normal/Auto Trigger edge Rising/Falling Coupling AC/DC Highest test voltage 1X : 40V, 10X : 400V Cursor Position XY, Trigger Y Waveform storage 1000 pictures + 1000 waveforms Roll mode Yes One-button AUTO Yes Waveform manager Yes Capture output Yes Voltage accuracy ±5% Frequency precision ±0.01% high precision Parameter 12 kinds in total Generator 14 kinds in total Extension USB export Power supply 5 V/2 A, 3 A, 4 A Dimensions 310 x 145 x 70 mm Included 1x FNIRSI 1014D Oscilloscope 2x Oscilloscope probes (100 MHz) 1x USB charger 1x Manual Downloads User Guide

    € 169,95

    Members € 152,96

  •  -50% Solder Fume Extractor ZD-153A

    Zhongdi Solder Fume Extractor ZD-153A

    Fumes released during the soldering process are potentially harmful to health. This solder fume extractor is securely fastened to the work table with a bracket. Thanks to the 3 axes, the solder fume extractor can be positioned perfectly, i.e. directly above the rising solder fumes. The harmful solder fumes are extracted by a powerful but quiet fan and filtered by an activated-carbon filter mat. Features Removes solder fumes Absorbs toxic gases and fumes from brazing operations Helps reduce the likelihood of headaches, eye irration and neusea Adjustable absorption angle for accurate placement Easy replaceable activated carbon filter High-performance fan Low noise and long life service Specifications Absorption capacity: 1 m³/min (max.) Power consumption: 23 W Power supply: 220-240 VAC Amount of activated carbon filter: 7 g Maximum absorption weight: 2 g Dimensions: 220 x 270 x 168 mm (W x H x D) Weight: 1.4 kg

    € 69,95€ 34,95

    Members identical

  •  -30% Soldering Mat ZD-154-1A

    Zhongdi Soldering Mat ZD-154-1A

    Out of stock

    This silicone soldering mat can be used as a base for all kinds of soldering work such as assembly or repair. Specifications Withstands 200-230°C constantly and 480-500°C for short periods Ideal for soldering electronics components or repairing PCBs, smartphones, etc. Color: Green Dimensions: 209 x 295 mm

    Out of stock

    € 9,95€ 6,95

    Members identical

  • LCR-T4 Mega328 Transistor Tester / ESR Meter

    Kuongshun LCR-T4 Component Tester (ESR Meter)

    Out of stock

    With this device, you'll be able to automatically to detect NPN and PNP transistors, n-channel and p-channel MOSFETs, diodes, thyristors, resistors, capacitors and many other components. It is also possible to measure certain characteristics of these devices as, for example, the current amplification factor of BJT or the gate threshold voltage of a MOSFET and much more.Features Automatic detection of NPN and PNP transistors, n-channel and p-channel MOSFETs, diodes (including double diode), thyristors, resistor and capacitor and other components Automatic testing of the pins of a component, and displaying on the LCD Detection of the transistor, MOSFET protection diode amplification coefficient and the base to determine the emitter transistor forward biased voltage Measurement of the gate threshold voltage and the gate capacitance of the MOSFET Simultaneous measurement of the of two resistors while displaying resistor symbol Measurement of a single diode reverse capacitance Measurements of capacitance, resolution 1 pF Identification of Darlington transistors via the base-emitter threshold voltage and current amplification factor Measurement of the bipolar transistor current amplification factor and the base-emitter threshold voltage 2x16 Characters LCD-Display (12864 LCD with green backlight) Test ranges Resistance: Max. 50 MΩ, resolution 0.1 Ω Capacitance: 25 pF – 100000 µF Inductance: 0.01 mH – 20 H Specifications One-button operation Automatic shutdown for improved battery life Shutdown current less than 20 nA

    Out of stock

    € 19,95

    Members € 17,96

  • PCB Holder with 4 Flexible Arms and LED Magnifier Lamp ZD-11M-3

    Zhongdi PCB Holder with 4 Flexible Arms and LED Magnifier Lamp ZD-11M-3

    Out of stock

    This PCB holder is ideal for any application where a third or fourth hand and a magnifying lamp are needed. Features The helping hands with 4 adjustable gooseneck arms. LED magnifying lamp with USB-C interface. Metal base with non-slip rubber strips. Comes with a cleaning ball, a sponge, a solder wire stand and rosin. Specifications Length of gooseneck arms: 270 mm LED magnifying lamp with 5-diopter lens Power supply via USB Dimensions (stand): 185 x 175 x 20 mm Weight: 620 g

    Out of stock

    € 19,95

    Members € 17,96

  • JOY-iT PS1440-C Programmable Laboratory Power Supply (1440 W)

    JOY-iT JOY-iT PS1440-C Programmable Laboratory Power Supply (1440 W)

    With the JOY-iT PS1440-C you get a programmable laboratory power supply, which provides you with DC voltages between 0.01 to 60 V and DC currents between 0.01 to 24 A at the voltage output. With the help of the intuitive control panel up to 9 different DC voltages can be programmed, stored and recalled, even individual settings of various protection and limiting functions (e.g. overvoltage protection) are programmable. The corresponding values can be set very conveniently via the keypad and/or the rotary control and are clearly displayed thanks to the high-resolution 2.4' color display. Features Complete device ready for immediate use Battery charging function Values can be entered conveniently via keypad Over current & over voltage protection adjustable Integrated RTC, NTC temperature sensor Included detailed documentation in English, German & French Specifications Input voltage 230 V Output voltage 0-60 V Output current 0-24 A Output power 0-1440 W Input voltage accuracy ±1% + 5 digits Output voltage accuracy ±0.3% + 3 digits Output current accuracy ±0.5% + 5 digits Battery voltage ±0.5% + 3 digits Input voltage measurement resolution 0.01 V Output voltage measurement resolution 0.01 V Current measurement resolution 0.01 V Battery voltage measurement resolution 0.01 V Response time in constant voltage mode 2 ms @ 0.1-5 A Load regulation in constant voltage mode ±0.1% + 2 digits Load regulation in constant current mode ±0.1% + 3 digits Measuring range electric charge 0-9999.99 Ah Measuring range energy 0-9999.99 Wh Statistical errors in electric charge & energy ±2% Output ripple 100 mV VPP @ 12 V150 mV VPP @ 24 V Sensor temperature detection range −10~+100°C (0-200°F) Sensor temperature detection accuracy ±3°C (±6°F) Working mode Step-down operation Screen brightness setting Level 0-5, 6 levels in total Permissible working temperature −10~+40°C (0-104°F) Dimensions 170 x 93 x 340 mm Included JT-PS1440-C power supply Power cord Manual Downloads Manual

    € 359,00

    Members € 323,10

  • PiCAN 2 – CAN-Bus Board for Raspberry Pi 2/3

    SK Pang Electronics PiCAN 2 - CAN-Bus Board for Raspberry Pi 2/3

    Out of stock

    This PiCAN 2 board provide CAN-Bus capability for the Raspberry Pi. It uses the Microchip MCP2515 CAN controller with MCP2551 CAN transceiver. Connection are made via DB9 or 3 way screw terminal. Easy to install SocketCAN driver. Programming can be done in C or Python. Features CAN v2.0B at 1 Mb/s High speed SPI Interface (10 MHz) Standard and extended data and remote frames CAN connection via standard 9-way sub-D connector or screw terminal Compatible with OBDII cable Solder bridge to set different configuration for DB9 connector 120Ω terminator ready Serial LCD ready LED indicator Foot print for two mini push buttons Four fixing holes, comply with Pi Hat standard SocketCAN driver, appears as can0 to application Interrupt RX on GPIO25 Optional fixing screws – select at bottom of this webpage Compatible with Raspberry Pi 2B, 3B and 3B+ Downloads User guide Schematic Rev B Writing your own program in Python Python3 examples in Github

    Out of stock

    € 44,95

    Members € 40,46

  • JOY-iT PSG9080 Programmable Signal Generator (80 MHz)

    JOY-iT JOY-iT PSG9080 Programmable Signal Generator (80 MHz)

    1 review

    The PSG9080 programmable signal generator can generate many different waveforms such as sine, square, triangle, pulse and custom waves. The signal generator has a wide frequency range from 1 nHz to 80 MHz and a sampling rate of 300 MSa/s. The housing is of high quality and offers non-slip feet for comfortable working. Different signal modulation methods, such as frequency modulation, phase modulation, amplitude modulation, pulse width modulation, frequency shift keying, are no longer a challenge with this device. The integrated measuring function also makes it possible to measure the frequency, period and duty cycle of external signals and display them on the screen in real time. The signal generator is very easy to operate with its intuitive key layout and high-resolution 3.5-inch colour LCD. Different settings can be saved in groups and thus recalled very quickly. In addition, the menu can be displayed in English, German and French. Features Modulation functions AM, FM, PM, ASK, FSK, PSK, PWM, Burst Sample rate 300 MSa/s Vertical wave resolution 14 bit Signal forms Lorentz pulse, pulse, half-wave, noise, exponential rise/fall, etc. Frequency rangesSineSquare, PulseTriangle, arbitraryTTL 1 nHz - 80 MHz1 nHz - 30 MHz1 nHz - 50 MHz1 nHz - 20 MHz Min. Frequency resolution 1 nHz Frequency accuracy ± 5 ppm Frequency stability ± 3 ppm / 1 year Permis. operation temp. 0 - 40°C Permis. operation humidity < 80% Permis. operation temp. 0 - 40°C Voltage / input 85 V - 264 VAC / 47 - 63 Hz Display 3.5' TFT colour LCD Connection BNC signal clips Dimensions 219 x 240 x 160 mm Scope of delivery JOY-iT PSG9080 signal generator 2x BNC signal clips Connection cable

    € 279,00

    Members € 251,10

  • Elektor 2 MHz LCR-meter Kit

    Eurocircuits Elektor 2 MHz LCR Meter Kit

    Out of stock

    Would you like to add an LCR Meter to your electronics workbench? Build your own! The Elektor 2 MHz LCR Meter Kit is an automatic impedance measuring bridge with extended functionality. Features Measures the resistance, capacitance and inductance of components with an impedance of 10 mΩ to 100 MΩ Test frequency from 50 Hz to 2 MHz Four possible test voltages (0.1, 0.2, 0.5 and 1 Vrms) Additional DC polarization up to 5 V for capacitors and 50 mA for inductors Two configurations possible: Standalone mode with main board + display extension Main board (without display) connected via USB to a computer running the user program (Windows, Linux, MacOS) Specifications Display Parameter valuesEquivalent circuitFrequencyImpedance ∣Z∣Phase ΦQ or DVoltage and current of DUTTest voltage (AC) and polarisation (DC)Range hold statusLabels for multi-function buttons Display size 4.1' (10.5 cm) | 240 x 128 dots Measurement range Parameter Value Inductance L 10 nH - 100 H Capacity C 1 pF - 100 mF Resistance R 10 mΩ - 100 MΩ Q 0 - 5000 for display Phase Φ -90° / +90° Test frequency 50 Hz to 2 MHz in 54 predefined stepsor any frequency within the range Accuracy Up to ± 0.1% ±1 of last digit Total current (MCU board + backlit display board) without polarization420 mA when polarizing DUTup to 650 mA Power supply 5 VDC/1 A USB A (not included)e.g. mobile phone mains charger PC software Windows, Linux, MacOS Dimensions (Hammond case) 6.5 x 4.2 x 2.1' (166 x 106 x 53 mm) Weight 1 kg All the necessary components are included for assembly and calibration: 2 populated PCBs (pushbuttons, rotary switch, and LCD)Note: Before shipping the operation of both assembled boards is carefully checked according to a protocol developed by the original designer Jean-Jacques Aubry. 4 BNC sockets (not assembled) 4 jumpers Hammond case drilled, machined, with printed front and side panels Kelvin cables with clips and 4 plugs Mini-USB / USB-A cable 24-way flat cable (15 cm) Aluminium button for rotary switch Full-color printed assembly manual (32 pages) Adjustment tool for trimmers Required tools Screwdriver, multimeter, and soldering iron. Time Total assembly and calibration time (depending on your skill): 60 to 90 minutes Downloads More downloads are available on the Elektor Labs platform. Elektor Jumpstarter This product is the result of a successful campaign on our electronics project support platform Elektor Jumpstarter. Readers and interested parties can submit their product ideas and, together with the Elektor development team, a finished product can be brought to market after extensive consideration and many tests. Note that these are always small series production runs, so the products are considered 'Elektor Collector Items'.

    Out of stock

    € 799,00

    Members € 719,10

  • SB Components Raspberry Pi Pico Breadboard Kit

    SB Components SB Components Raspberry Pi Pico Breadboard Kit

    Raspberry Pi Pico Breadboard Kit helps the user to configure GPIO of Raspberry Pi Pico for use with external devices.Raspberry Pi Pico Breadboard Kit is a multi-purpose Kit that consists of a “400 points half-size breadboard” on top, a Programmable Buzzer, 4 programmable LEDs, 4 push buttons, and dedicated 5 V, 3V3, and GND pins at a single place. SB Components developed Raspberry Pi Pico Breadboard Kit with advanced features like independently controllable LEDs, Switches, a 400 points half-size breadboard that helps the user to prototype their projects with Raspberry Pi Pico in an efficient way.Raspberry Pi Pico Breadboard Kit can be interfaced with Raspberry Pi Pico from which a user can run electronics experiments, prototypes, mini robots, games, interact with Linux-ready Raspberry Pi, Exploration of circuits, etc. One can also connect external components with the breadboard provided on the top of the Raspberry Pi Pico Breadboard Kit.Features Four independent controlled LEDs Four independent controlled push buttons Compatible with Pico A 400 points half size breadboard Programmable buzzer Dedicated 5 V, 3V3 and Gnd pins for easy use Specifications Operating voltage 3.3 VDC Communication interface GPIO Dimensions 85 x 133 mm Applications Electrical experiments Prototypes Mini robots Games Exploration of circuits Downloads Manual Example codes Circuit diagram GitHub Included 1x Pico Breadboard Kit 5x Male to Male Jumper Wires 5x Female to Female Jumper Wires 5x Male to female Jumper Wires Note: Raspberry Pi Pico is not included.

    € 18,95

    Members € 17,06

  • MonkMakes Breadboard for Pico

    MonkMakes MonkMakes Breadboard for Pico

    Solderless breadboard labelled for the Raspberry Pi Pico It can be tricky to work out which pin is which when the Raspberry Pi Pico is attached to solderless breadboard. The MonkMakes Breadboard for Pico solves this problem by labelling the Pico pins on the 400 point solderless breadboard. Features 400 tie point 2 power busses Size: 8.2 x 5.5 x 0.85 cm Self-adhesive back

    € 5,95

    Members € 5,36

  •  -21% Andonstar AD407 Pro HDMI Digitale Microscoop met 7` LCD-scherm

    Andonstar Andonstar AD407 Pro 7" HDMI Digital Microscope

    The Andonstar AD407 Pro microscope is suitable for various applications such as soldering SMDs or repair work. The microscope has a large adjustable 7' LCD display and comes with a remote. Compared to AD407, AD407 Pro offers an extra-high stand, which makes soldering of components even easier. Specifications Screen size 7 inch (17.8 cm) Image sensor 4 MP Video output UHD 2880x2160 (24fps)FHD 1920x1080 (60fps/30fps)HD 1280x720 (120fps) Video format MP4 Magnification Up to 270 times (27 inch HDMI monitor) Photo resolution Max. 12 MP (4032x3024) Photo format JPG Focus range Min. 5 cm Frame Rate Max. 120fps Video interface HDMI Storage microSD card (up to 64 GB) Power source 5 V DC Light source 2 LEDs with the stand Stand size 20 x 18 x 32 cm Included 1x Andonstar AD407 Pro Digital Microscope 1x Metal stand with 2 LEDs 1x UV filter (already assembled in the lens) 1x IR remote 1x Switch cable 1x Power adapter 1x Wrench 2x Metal clips 1x HDMI cable 1x User manual Downloads User Manual Model Comparison AD407 AD407 Pro AD409 AD409 Pro-ES Screen size 7 inch (17.8 cm) 7 inch (17.8 cm) 10.1 inch (25.7 cm) 10.1 inch (25.7 cm) Image sensor 4 MP 4 MP 4 MP 4 MP Video output 2160p 2160p 2160p 2160p Interfaces HDMI HDMI USB, HDMI, WiFi USB, HDMI, WiFi Video format MP4 MP4 MP4 MP4 Magnification Up to 270x Up to 270x Up to 300x Up to 300x Photo resolution Max. 4032x3024 Max. 4032x3024 Max. 4032x3024 Max. 4032x3024 Photo format JPG JPG JPG JPG Focus distance Min. 5 cm Min. 5 cm Min. 5 cm Min. 5 cm Frame rate Max. 120f/s Max. 120f/s Max. 120f/s Max. 120f/s Storage microSD card microSD card microSD card microSD card PC support No No Windows Windows Mobile connection No No WiFi + Measurement WiFi + Measurement Power source 5 V DC 5 V DC 5 V DC 5 V DC Light source 2 LEDs with the stand 2 LEDs with the stand 2 LEDs with the stand 2 LEDs with the stand Endoscope No No No Yes Stand size 20 x 12 x 19 cm 20 x 18 x 32 cm 18 x 20 x 30 cm 18 x 20 x 32 cm Weight 1.6 kg 2.1 kg 2.2 kg 2.5 kg Price €259.00€199.00 €289.00€229.00 €399.00€279.00 €449.00€299.00

    € 289,00€ 229,00

    Members identical

  •  -17% Andonstar AD249S-M 3-Lens HDMI Digitale Microscoop met 10,1` LCD-scherm

    Andonstar Andonstar AD249S-M 10.1" 3-Lens HDMI Digital Microscope

    Out of stock

    This versatile microscope covers a wide magnification range (60-240x, 18-720x, 1560-2040x) with 3 lenses. With this digital microscope, you can examine plants, insects, gems and coins, or do electronic work such as repairing or making circuit boards. Specifications AD246S-M AD249S-M Magnification Lens A 18-720 18-720 Focus range 12-320 mm 12-320 mm Lens D 1800-2040 1800-2040 Focus range 4-5 mm 4-5 mm Lens L 60-240 60-240 Focus range 90-300 mm 90-300 mm Screen size 7 inch (17.8 cm) 10 inch (25.7 cm) Video resolution (max.) UHD 2880x2160 (24fps) UHD 2880x2160 (24fps) Video format MP4 MP4 Photo format JPG JPG Photo resolution 5600x2400 (with interpolation) 5600x2400 (with interpolation) Frame rate Max. 120fps Max. 120fps HDMI output Yes (support dual-screen display) Yes (only HDMI monitor displays) PC output Yes Yes Stand size 20 x 18 x 30 cm 20 x 18 x 30 cm Included 1x Andonstar AD249S-M Digital Microscope 3x Lenses (A, D & L) 1x Slide holder 1x 32 GB microSD card 1x USB cable 1x Switch cable 1x HDMI cable 1x Remote control 5x Prepared Slides 1x Observation box 1x Tweezers 1x User manual Downloads User Manual Software

    Out of stock

    € 289,00€ 239,00

    Members identical

  • Breadboard (830 Tie Points)

    Breadboard (830 Tie Points)

    Specifications Terminal strip, tie-point 630 Distribution strips, tie-point 200 Solderless breadboard (MB-102) Wire size: Suitable for 20-29 AWG wires, jumper wire of 0.8 mm diameter Material: ABS. Transparent material Size: 16.5 x 5.3 x 0.85 cm Brand new and high quality They allow electronic components to be interconnected in an almost endless number of ways to produce working circuits Because no soldering is required, modifying or revising the circuits can be done quite easily The breadboard consists of a set of formed metal sockets inserted into a durable plastic housing Phosphor bronze nickel plated spring clips Adhesive sheet on the bottom of the board

    € 5,95

    Members € 5,36

  • Peak Atlas DCA55 Semiconductor Analyser

    Peak Peak Atlas DCA55 Semiconductor Analyser

    The DCA55 is great for automatically identifying the type of semiconductor on the test leads as well as the pinout and many other parameters. Supports transistors MOSFETs, JFETs (gate pin only can be identified), diodes, LEDs and lots more. Automatically identifies type of component, pinout and other important parameters. Now features transistor leakage measurement and Germanium/Silicon identification. Component Support Bipolar transistors (NPN/PNP inc Silicon/Germanium) Darlington transistors (NPN/PNP) Enhancement mode MOSFETs (N-Ch and P-Ch) Depletion mode MOSFETs (N-Ch and P-Ch) Junction FETs (N-Ch and P-Ch). Only gate lead identified. Diodes and diode networks (2 and 3 lead types). LEDs and bi-colour LEDs (2 lead and 3 lead types). Low power sensitive Triacs and Thyristors (<5 mA trigger and hold) Measurements Part type identification Pinout identification BJT current gain (hFE) BJT base emitter voltage (Vbe) BJT collector leakage current MOSFET gate threshold voltage Diode forward voltage drop (Vf) Specifications Analyser type Transistors, Diodes, LEDs, MOSFETs, JFETs Pinout detection Full pinout (only Gate on JFETs) Pinout configuration Connect any way round Transistor measurements Vbe, hFE, Iceo MOSFET measurements Vgs(on) Diode measurements Vf Probe type Universal grabber type Battery Single AAA cell (supplied). Life typically 1300 ops Test conditions Typically 5 mA, 5 V peak Display type Alphanumeric LCD (with backlight) Included DCA55 Semiconductor Component Analyser instrument Comprehensive illustrated user guide Fitted universal hook probes AAA Alkaline battery Downloads Datasheet (EN) User Guide (EN) User Guide (FR) User Guide (DE) User Guide (IT)

    € 59,95

    Members € 53,96

  • JOY-iT DPH5005 Programmable Buck & Boost Power Supply

    JOY-iT JOY-iT DPH5005 Programmable Buck & Boost Power Supply

    2 reviews

    The DPH5005 meets many requirements of a lab power supply. This power supply combines analog and digital technologies in an advanced design with outstanding precision and accuracy. The adjustable output reaches up to 50 V or 5 A and can be precisely configured in 10 mV or 1 mA steps. The power supply unit is additionally equipped with a switch-off parameter memory and ten programmable data memories. The operation of the unit has been optimized for particularly easy operation and the colour display offers particularly detailed and comprehensive information. Among other things, the current voltage and current values, presettings and output powers can be displayed here. Dynamic notification symbols also facilitate clarity. The additional settings menu offers maximum control of overcurrent and overvoltage values as well as other parameters. The DPH5005 offers modern design and advanced technology in a compact package, making it the ideal power supply. In addition, you can supplement the laboratory power supply with the optionally available housing. Specifications Display Type LCD Input Voltage 6-50 V (DC) Output Voltage 0-50 V Output Current 0-5 A Output Power 0-250 W Voltage Resaolution 0.01 V Current Resolution 0.001 A Special Features Programmable, slim Ripple 100 mVpp Size (Display Module) 43 x 79 x 38 mm Size (Power Module) 93 x 35 x 72 mm Display Size 1.5' (3.8 cm) Weight 202 g Items Shipped Display and power module, 2 connection wires Downloads Datasheet Manual PC Software / Android APK

    € 74,95

    Members € 67,46

Discover Elektor's measuring instruments collection

Elektor is the place for professionals and enthusiasts involved in electronics. We not only offer a source of education and inspiration, but also an extensive range of measuring instruments. These tools are essential for anyone who wants to take their projects to the next level of precision. Whether you are working on a complex design or testing a basic component, Elektor measuring instruments guarantee reliability and quality.

Essential measuring tools for your Projects

Elektor understands that good measuring instruments are the heart of every electronics project. That is why we have a wide range of oscilloscopes, multimeters, signal generators and more in our range. These tools have been carefully selected to meet the needs of both the hobbyist and the professional. With our measuring instruments you can tackle any electronics challenge with confidence.

In the rapidly changing world of electronics, it is crucial to have access to the latest technology. Our measuring instruments are equipped with the latest developments in electronics, so that you are always ahead of the curve. At Elektor you will find everything you need to support your electronics projects, from simple tools to advanced measuring equipment.

More than just measuring instruments

At Elektor it is more than just offering tools; we provide a community and a platform for knowledge sharing. In addition to measuring instruments, Elektor magazine offers ideas, information and inspiration for your next project. We are a source of innovation for electronics designers, both for professional use and for hobby projects.

Order your measuring instruments from Elektor

  • Quality and Diversity: An extensive range of high-quality measuring instruments.
  • Competitive Prices: Competitive prices with extra benefits for Elektor members.
  • Expertise and Support: Years of experience in electronics and a reliable source of knowledge and inspiration.

Prepare for success in your electronics projects with Elektor measuring instruments. Visit our collection today and find the perfect tools to suit your needs. With Elektor you choose quality, innovation and a community that is as passionate about electronics as you are.
