Waveshare RP2040-PiZero Development Board

  • BrandWaveshare

Description

Waveshare RP2040-PiZero is a high-performance and cost-effective microcontroller board with onboard DVI interface, TF card slot and PIO-USB port, compatible with Raspberry Pi 40-pin GPIO header, easy to develop and integrate into the products.

Features

  • RP2040 microcontroller chip designed by Raspberry Pi
  • Dual-core ARM Cortex M0+ processor, flexible clock running up to 133 MHz
  • 264 KB of SRAM, and 16 MB of onboard Flash memory
  • Onboard DVI interface can drive most HDMI screens (DVI compatibility required)
  • Supports using as a USB host or slave via onboard PIO-USB port
  • Onboard TF card slot for reading and writing TF card
  • Onboard Lithium battery recharge/discharge header, suitable for mobile scenarios
  • USB 1.1 with device and host support
  • Drag-and-drop programming using mass storage over USB
  • Low-power sleep and dormant modes
  • 2x SPI, 2x I²C, 2x UART, 4x 12-bit ADC, 16x controllable PWM channels
  • Accurate clock and timer on-chip
  • Temperature sensor
  • Accelerated floating-point libraries on-chip

Downloads

Product form

Waveshare RP2040-PiZero is a high-performance and cost-effective microcontroller board with onboard DVI interface, TF card slot and PIO-USB port, compatible... Read more

€ 17,95 (incl. VAT)
Members € 16,16

      Details

      SKU: 20657
      EAN: 25506

      Description

      Waveshare RP2040-PiZero is a high-performance and cost-effective microcontroller board with onboard DVI interface, TF card slot and PIO-USB port, compatible with Raspberry Pi 40-pin GPIO header, easy to develop and integrate into the products.

      Features

      • RP2040 microcontroller chip designed by Raspberry Pi
      • Dual-core ARM Cortex M0+ processor, flexible clock running up to 133 MHz
      • 264 KB of SRAM, and 16 MB of onboard Flash memory
      • Onboard DVI interface can drive most HDMI screens (DVI compatibility required)
      • Supports using as a USB host or slave via onboard PIO-USB port
      • Onboard TF card slot for reading and writing TF card
      • Onboard Lithium battery recharge/discharge header, suitable for mobile scenarios
      • USB 1.1 with device and host support
      • Drag-and-drop programming using mass storage over USB
      • Low-power sleep and dormant modes
      • 2x SPI, 2x I²C, 2x UART, 4x 12-bit ADC, 16x controllable PWM channels
      • Accurate clock and timer on-chip
      • Temperature sensor
      • Accelerated floating-point libraries on-chip

      Downloads
