Waveshare Polysilicon Solar Panel (18 V, 10 W)

  • BrandWaveshare

Description

This polysilicon solar panel (18 V/10 W) provides stable performance with a high conversion efficiency of >20%.

Specifications

Solar cell type Polysilicon
Output power tolerance ±3%
Operating voltage 17.6 V
Open circuit voltage 21.6 V
Cell quantity 36 (4x9)
Power 10 Wp (max)
Conversation efficiency >20%
Operating current 0.57 A
Short circuit current 0.61 A
Standard system voltage 1000 V (Max)
Operating temperature -40°C ~ +85°C
Pressure on panel 30 m/s (200 kg/sq.m) (Max)
Cable Length 90 cm, DC plug, OD 3.5 mm ID 1.35 mm
Frame material Anodic oxidation aluminum alloy
Dimensions 340 x 232 x 17 mm
Weight 0.935 kg
Product form

This polysilicon solar panel (18 V/10 W) provides stable performance with a high conversion efficiency of >20%. Specifications Solar cell type Polysilicon... Read more

€ 19,95 incl. VAT
Members € 17,96

      Details

      SKU: 20489
      EAN: 19598

      Description

      This polysilicon solar panel (18 V/10 W) provides stable performance with a high conversion efficiency of >20%.

      Specifications

      Solar cell type Polysilicon
      Output power tolerance ±3%
      Operating voltage 17.6 V
      Open circuit voltage 21.6 V
      Cell quantity 36 (4x9)
      Power 10 Wp (max)
      Conversation efficiency >20%
      Operating current 0.57 A
      Short circuit current 0.61 A
      Standard system voltage 1000 V (Max)
      Operating temperature -40°C ~ +85°C
      Pressure on panel 30 m/s (200 kg/sq.m) (Max)
      Cable Length 90 cm, DC plug, OD 3.5 mm ID 1.35 mm
      Frame material Anodic oxidation aluminum alloy
      Dimensions 340 x 232 x 17 mm
      Weight 0.935 kg
