Description
The DLOS8 is an open-source outdoor LoRaWAN Gateway. It lets you bridge LoRa wireless network to an IP network via Ethernet, WiFi or 3G. The LoRa wireless allows users to send data and reach extremely long ranges at low data-rates.
The DLOS8 uses Semtech packet forwarder and fully compatible with LoRaWAN protocol. It includes an SX1301 LoRaWAN concentrator, which provides ten programmable parallel demodulation paths.
DLOS8 has pre-configured standard LoRaWAN frequency bands to use for different countries. User can also customize the frequency bands to use in their LoRaWAN network.
DLOS8 can communicate with ABP LoRaWAN end node without LoRaWAN server. The system integrator can use it to integrate with their existing IoT Service without set up own LoRaWAN server or use 3rd party LoRaWAN service.
Features
- Managed by SSH via LAN or WiFi, Web GUI
- Open Source OpenWrt system
- Emulates 49x LoRa demodulators
- Outdoor LoRaWAN Gateway
- LoRaWAN packet filtering
- Ten programmable parallel demodulation paths
- Farseeing LED indicator
- External fibreglass antenna
- Built-in GPS module for location & timing
- 802.3af PoE
- IP65
- Lighting Protection
- Power Consumption:12 V, 300 mA ~ 500 mA
- 1x 10M / 100M RJ45 Ports
- 1x USB host port
- 2.4G WiFi (802.11 bgn)
Applications
- Logistics and Supply Chain Management
- Smart Buildings & Home Automation
- Smart Metering
- Smart Cities
- Smart Agriculture
- Smart Factory
