Learning Digital Electronics (Bundle)

Description

Master digital electronics – the hands-on way!

This bundle includes the book Learning Digital Electronics, featuring 20+ practical projects in Logic and Circuit design, as well as a 100-piece kit – so you can start building logic circuits, counters, displays, and more right away.

Learning Digital Electronics (Book)

This book is a practical guide to digital electronics, covering the essential components of modern digital systems: number systems, logic gates, Boolean algebra, combinational and sequential logic, and more.

Through more than 20 structured projects, you’ll design and build digital systems using real-world components such as logic gates, multiplexers, decoders, flip-flops, counters, and shift registers. The projects range from basic LED logic circuits to digital locks, display systems, traffic light controllers, and timing-based designs.

Selected projects introduce the use of tools such as CircuitVerse for circuit simulation, while several designs make use of 74HC-series logic devices, commonly used in digital hardware prototyping.

Inside, you’ll find:

  • Clear coverage of number systems and binary arithmetic
  • Logic gate fundamentals and universal gate implementations
  • Step-by-step projects using flip-flops, counters, and registers
  • Real-world design with 74HC-series logic chips
  • Techniques for designing combinational and sequential systems

This book takes a design-first, application-driven approach to digital electronics—built around working circuits, tested logic, and hands-on experimentation.


Learning Digital Electronics (Kit)

This kit has been specially developed to complement the book "Learning Digital Electronics". Since all necessary components are included, you can complete every practical project in the book directly.

Kit contents

  • 2x 74HC08 AND gate chip
  • 2x 74HC00 NAND gate chip
  • 1x 74HC86 XOR gate chip
  • 1x 555 timer chip
  • 1x 74HC161 counter chip
  • 1x 74HC164 shift register
  • 1x CD4511 7-segment decoder
  • 1x CD4027 JK flip-flop
  • 1x BC337 NPN transistor
  • 1x KPS-5161 7-segment common-cathode display
  • 1x Light dependent resistor (LDR)
  • 4x 10 KΩ resistors
  • 8x 1 KΩ resistor
  • 2x 47 KΩ resistors
  • 1x 100 KΩ resistor
  • 4x 2.7 KΩ resistors
  • 1x 5.6 KΩ resistor
  • 1x 150 KΩ resistor
  • 1x 10 μF capacitor
  • 2x 0.01 μF capacitor
  • 2x 100 nF capacitor
  • 8x Small red LED
  • 1x Small green LED
  • 1x Small orange LED
  • 4x Pushbutton switches
  • 1x Active buzzer
  • 1x Battery holder for 3x AA batteries (batteries not included)
  • 1x Breadboard
  • 40x Male-to-male jumper wires (length: 200 mm)
Product form

Master digital electronics – the hands-on way! This bundle includes the book Learning Digital Electronics, featuring 20+ practical projects in... Read more

€ 69,95 € 59,95 (incl. VAT)
Members identical

    Details

    SKU: 21235
    EAN: 7442105135165
    Author: Dogan Ibrahim
    Language: English
    Pages: 128 (Full Color)
    Format: 17 x 24 cm (Paperback)
