OPEN-SMART GPS - Serial GPS Module for Arduino (APM2.5 Flight Control)

  • BrandKuongshun

Description

The GT-7U GPS module, with its high sensitivity, low power consumption, miniaturization, and its extremely high tracking sensitivity, delivers an extended area of coverage. In an area that the conventional GPS receiver would fail, such as narrow urban sky, dense Jungle environment, GT-7U can achieve high-precision positioning.

Its compact size makes it suitable for applications in vehicles, mobile phones, video cameras, and other mobile positioning systems, and it is an excellent choice for GPS applications.

Specifications

Operating Frequency L1 (1575.42 ±10 MHz)
Operating Voltage 3.3 - 5.2 V
Operating Current Normal Mode: 50 mA
Power-Saving Mode: 30 mA
Communication Interface TTL serial port, microUSB interface
Serial Port Baud Rate 9600 bps
Communication format 8N1
Interface Logic Voltage 3.3 or 5 V
External Antenna Inteface IPX
Dimensions 2.2 x 2.1 x 0.5 cm
Weight 8.5 g
Product form

The GT-7U GPS module, with its high sensitivity, low power consumption, miniaturization, and its extremely high tracking sensitivity, delivers an... Read more

€ 10,95 incl. VAT
Members € 9,86

      Details

      SKU: 18733
      EAN: 018733

      Description

      The GT-7U GPS module, with its high sensitivity, low power consumption, miniaturization, and its extremely high tracking sensitivity, delivers an extended area of coverage. In an area that the conventional GPS receiver would fail, such as narrow urban sky, dense Jungle environment, GT-7U can achieve high-precision positioning.

      Its compact size makes it suitable for applications in vehicles, mobile phones, video cameras, and other mobile positioning systems, and it is an excellent choice for GPS applications.

      Specifications

      Operating Frequency L1 (1575.42 ±10 MHz)
      Operating Voltage 3.3 - 5.2 V
      Operating Current Normal Mode: 50 mA
      Power-Saving Mode: 30 mA
      Communication Interface TTL serial port, microUSB interface
      Serial Port Baud Rate 9600 bps
      Communication format 8N1
      Interface Logic Voltage 3.3 or 5 V
      External Antenna Inteface IPX
      Dimensions 2.2 x 2.1 x 0.5 cm
      Weight 8.5 g
