Elektor SDR Shield 2.0

  • BrandElektor Labs

Description

This board is a newer version of the Elektor SDR Reloaded, the difference is that on this new version with two PLL outputs and two LF-outputs, which are accessible via additional connectors on the board (not included in the kit). This allows the user to use this Arduino shield as a signal generator, SW transmitter or even transceiver.

Specifications

Operating Voltage 5 V and 3.3 V from Arduino
Frequency Range 150 kHz to 30 MHz
Sensitivity 1 µV
Overall Gain 40 dB
Maximum signal level at antenna 10 mV
Dynamic Range 80 dB

Please note: The module doesn't come pre-soldered.

Links

Product form

This board is a newer version of the Elektor SDR Reloaded, the difference is that on this new version with... Read more

Out of stock

€ 39,95 incl. VAT
Members € 35,96

    Details

    SKU: 18515
    EAN: 018515

    Description

    This board is a newer version of the Elektor SDR Reloaded, the difference is that on this new version with two PLL outputs and two LF-outputs, which are accessible via additional connectors on the board (not included in the kit). This allows the user to use this Arduino shield as a signal generator, SW transmitter or even transceiver.

    Specifications

    Operating Voltage 5 V and 3.3 V from Arduino
    Frequency Range 150 kHz to 30 MHz
    Sensitivity 1 µV
    Overall Gain 40 dB
    Maximum signal level at antenna 10 mV
    Dynamic Range 80 dB

    Please note: The module doesn't come pre-soldered.

    Links
